900w Dc Converter Buck Cc Cv Lcd Display Programmable Ttl 15-80v To 0-60v 15a

US $116.89

Shen Zhen, China
Mar 8th

Open on mobile:
QR code

900W DC Converter Buck CC CV LCD Display Programmable TTL 15-80V to 0-60V 15A Introduction DPS6015A is a single-output programmable power switching power supply. Specifications are 60V, 15A, 900W, output power, small size, DC-DC modular design. At the same time with a TTL serial communication interface for serial communication protocol, allowing users to secondary development, according to your design and testing requirements, provide versatile solutions. main characteristics BUCK architecture based switching power supply technology, operating frequency up to 150KHz very wide DC input voltage range: DC15V ~ 80V, suitable for a variety of pre-input power operating buttons and multi-encoder combined operation, easy to use high accuracy and high resolution 10mV / 10mA low ripple and low noise constant CC, CV constant voltage and output status LEDs ON lLCD1602 LCD can be used to adjust the knobs and buttons, the voltage and current regulation quantifiable display output voltage, output current, output power, output power (AH), working hours, the temperature of the power device 2V minimum pressure can still stable has a flexible output shutdown function keys to open or close the output M0 ~ M9 total of 10 sets of parameters set, you can call up at any time convenient onboard operating tips or buzzer alarm function with isolated TTL serial communication, improved communication protocols to facilitate centralized control specific isolation port 485 for industrial control Technical indicators Input voltage range: 15V ~ 80V Output voltage adjustment range : 0 ~ 60V Output current range : 0 ~ 15A output power: 0 ~ 900W Resolution of output voltage setting: 10mV output current setting resolution: 10mA Output ripple <20mVpp (input 40V, output 12V, current 8A) 100Hz volatility transmission ratio <1/10000 Typical efficiency of 88% (input 40V, output 36V, current 8A) Voltage and current display precision :10mV, 10mA Voltage display error :± 1% + 50mV Current display error: ± 2% + 10mA Response time <50ms Store operations M0 ~ M9 total of 10 sets of parameters are stored OTP type of protection Onboard radiator cooling mode, the fan-cooled Operating ambient temperature :0 ~ 40 °C Storage temperature :-20 ~ 70 °C Environment designed for indoor use, maximum humidity of 80% Dimensions (L×W×H) 140 × 100 × 43 (mm) Weight: 326g Package include: 1 x DC 900W 15-80V to 0-60V 15A Buck Converter CC CV LCD Display Programmable TTL We accept PayPal only. 1.Items are shipped from china.we will send out within 1 bussiness day after receive the payment. 2.We only ship to ebay confirmed address. So before bidding, please kindly verify your ebay address. 3.Shipping to USA takes 8-18 days in normal condition by E-packet with tracking number. Shipping to most other countries takes about 12-30 days via Economy Int'l Airmail. Less than $40, without tracking number,if you request tracking number,please pay $3 more and let me know. Over $40,with tracking number free.The shipping time depends on your location and local postal service,as well as the weather condition along the shipping,sometimes may take longer,.please contact us to confirm before leave feedback or open case. 4.Express shipping: Extra $20 --$25 will be charged for the first 500 grams for most countries. Contact us if you need this service. 1.If you are not satisfied when you receive your item, please return it within 30 days for a replacement or money back. Please contact us before you return it. 2.If item is defective in 30 days, We will send you a replacement without extra charger, or offer refund after we receive the defective item. 3.If item is defective after 30 days, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee. We are honest seller and do our best to serve you. So if you have any concerns,please don’t hesitate to contact us by ebay message. We will do your best to help you out.please don’t leave negative/ neutral feedback or open case before contact us. On Mar-07-15 at 19:26:03 PST, seller added the following information:
