9dof Mpu-9150 3 Axis Gyroscope+accelerometer+magnetic Field Replace Mpu 6050 Dx

US $7.83

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

?? Features: This breakout board makes it easy to prototype with the InvenSense MPU-9150 by breaking out all the pins you need to standard 0.1" spaced headers. The board also provides I2C pullup resistors and a solder jumper to switch the I2C address of the device. The MPU-9150 is a System in Package (SiP) that combines two chips: the MPU-6050, which contains a 3-axis gyroscope, 3-axis accelerometer, and an onboard Digital Motion Processor (DMP) capable of processing complex 9-axis MotionFusion algorithms; and the AK8975, a 3-axis digital compass. The part's integrated 9-axis MotionFusion algorithms access all internal sensors to gather a full set of sensor data. The part is offered in a 4x4x1mm LGA package and is upgrade-compatible with the MPU-6050 integrated 6-axis MotionTracking device, providing a simple upgrade path and making it easy to fit on space constrained boards. Specifications: Digital-output 9-axis MotionFusion data in rotation matrix, quaternion, Euler Angle, or raw data format Tri-Axis angular rate sensor (gyro) with a sensitivity up to 131 LSBs/dps and a full-scale range of ±250, ±500, ±1000, and ±2000dps Tri-Axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g Tri-axis compass with a full scale range of ±1200µT Reduced settling effects and sensor drift by elimination of board-level cross-axis alignment errors between accelerometer, gyroscope, and compass VDD Supply voltage range of 2.4V-3.46V;VLOGIC of 1.8V±5% or VDD Gyro operating current: 3.6mA (full power, gyro at all rates) Gyro + Accel operating current: 3.8mA (full power, gyro at all rates, accel at 1kHz sample rate) Gyro + Accel + Compass + DMP operating current: 4.25mA (full power, gyro at all rates, accel at 1kHz sample rate, compass at 8Hz rate) Accel low power mode operating current: 10uA at 1Hz, 20uA at 5Hz, 70uA at 20Hz, 140uA at 40Hz Full Chip Idle Mode Supply Current: 8µA 400kHz Fast Mode I?C serial host interface On-chip timing generator with ±1% frequency variation over full temperature range 10,000g shock tolerant I2C Pullup Resistors populated on board. All Pins Broken Out to Standard 0.1" Spaced Headers Solder Jumper for Switching LSB of I2C Address Package Included: 1 x 9DOF MPU-9150 3 Axis Gyroscope+Accelerometer+magnetic field replace MPU 6050 We offer WORLDWIDE SHIPPING. (Except China, Italy, and Croatia) Orders will be processed and dispatched within 24-48 hours after payment is clear. We only ship to confirmed eBay addresses. Your eBay address MUST MATCH your Shipping address. If you have not received your shipment within 30 business days from payment, please contact us. We will track the shipment and get back to you as soon as possible. Our goal is customer satisfaction! Please note that estimated delivery time is depended on destination countries, and may subject to customs clearance process, and weather condition in your area. Country Delivery Time (days) Not including Handling time, weekend, and holidays 9-12 13-18 19-24 25-29 30-35 >35 United States 5% 50% 30% 11% 5% Refund United Kingdom 10% 63% 19% 3% 4% Refund Australia 21% 50% 14% 7% 7% Refund France 11% 29% 44% 10% 7% Refund Germany 11% 22% 30% 21% 16% Refund Canada 0% 47% 31% 18% 4% Refund Spain 4% 25% 48% 13% 11% Refund We accept PayPal payment only, and must be received within 3 days from the date of purchase. Please leave note in PayPal when making the payment if you have any special requests. Orders will be processed instantly and dispatched within 1-2 days, so we do NOT accept any email/message note after you place orders. IMPORTANT! PLEASE READ! Buyers are responsible for import duties, custom fees and taxes, if any. Please check with your country??s custom office to determine the additional costs impose on the item prior to buying. We offer 14 days return policy. Please contact us within 14 days t from the date you receive your order if you have any issues with the product and would like to return. All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return, and your eBay ID. We will refund YOUR FULL WINNING BID AMOUNT, upon receipt of the item in its original condition and packaging with all components and accessories included, AFTER BOTH Buyer and Seller cancel the transaction from eBay. OR, you may choose to have a replacement. Buyer is responsible for return shipping cost. We strive for our customer satisfaction at best possible. If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a week. We will reply you ASAP. If no response within 24 Hours, please check the spam in your mail box. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for help. Our aim is to provide Top Level Customer Service, normally so we will try our best to solve any problem you have. Please DON'T leave negative or neutral feedback if you haven't received item in 30 days, because we have mentioned the shipping time repeatedly. We maintain high standards of excellenceand strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Dec-27-14 at 04:32:26 PST, seller added the following information:
