A & M Instruments Wattmeter Watt 135 Metal Frame Square 1.75" 50 Microamp Dc New

US $270

Westerville, Ohio, United States
Jun 7th

Open on mobile:
QR code

FOR SALE IS A BRAND NEW A & M INSTRUMENTS DC WATTMETER. WILL REGISTER FROM 10 TO 100 WATTS. THE PART NUMBER IS 135-539 AND THE NSN IS 6625011045828. THE SPECIFICATIONS ARE AS FOLLOWS: AACT Circuit Current FOR Which Designed DC AAPB Dielectric Withstanding Voltage IN Volts 1500.0 ABHP Overall Length 1.625 inches maximum ABKQ Center TO Center Distance Between Mounting Facilities Parallel TO Length 1.306 inches minimum and 1.318 inches maximum ABKR Center TO Center Distance Between Mounting Facilities Parallel TO Width 1.306 inches minimum and 1.318 inches maximum ABKW Overall Height 1.810 inches maximum ABMK Overall Width 1.810 inches maximum ABTB Mounting Hole Diameter 0.125 inches nominal ADZC Environmental Protection Shock resistant and vibration resistant AKYN Furnished Items AND Quantity Nut 4; washer 4 AMKD Indicator Type Dial W/pointer AMQY Installation Design Panel ANRL Mounting Arrangement Style Four hole/stud rectangular/square ANTG Sensitivity Rating 50.0 microamperes APMM Dial Scale Marking Color Red single indicator single range and green single indicator single range APPN Accuracy IN Percent -3.0/+3.0 at full scale single indicator single range APSN Unable TO Decode Unable to decode or unable to decode APST Meter Depth Behind Mounting Flange 1.000 inches maximum APSW Meter Body Diameter Behind Mounting Flange 1.510 inches maximum AQFY Background Color White single indicator single range ASSS Pointer Color Black single indicator single range AWZJ Power Source External AXHR Mounting Facility Type AND Quantity 4 screw and 4 unthreaded hole BHDC Scale Graduation Type Nonlinear single indicator single range BHMW Measurement Range +10.0/+100.0 watts single indicator single range BHSX Unable TO Decode Unable to decode CBBL Features Provided Magnetic shield and zero adjuster CTTD Circuit Attachment Method AND Quantity 2 solder lug FEAT Special Features Ruggedized MARK Special Markings Red band 0 to 12.7 ua deflection; green band 12.7 to 50 ua deflection; 10 W line at 14.15 ua deflection; 100 W line at 44.75 ua deflection MATT Material Steel NHCF Nuclear Hardness Critical Feature Nonhardened SFTT Surface Treatment Enamel semigloss SPCL Special Test Features Conform to MIL-M-10304/24, type MR13A050DCUAR STYL Style Designator Rectangular flush mtg ZZZV FSC Application Data Test set, elect. equip. IF YOU HAVE ANY QUESTIONS, PLEASE FEEL FREE TO CALL ME 1-614-580-0951. You will not be disappointed. My feedback speaks for itself. If you have any questions please email me and check out the other items I have for sale. If you have problems with your order, PLEASE CONTACT ME BEFORE LEAVING FEEDBACK. Thanks, Mark ATTENTION! – ATTENTION! – NOTICE! – NOTICE! BEFORE LEAVING FEEDBACK PLEASE CONTACT ME. I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE. IF YOU BOUGHT THE WRONG THING, IT IS BROKEN, IF SHIPPING TOOK TOO LONG OR EVEN IF YOU’RE HAVING A BAD DAY. I WANT TO HELP!! I WANT TO KEEP MY FEEDBACK CLEAN.
