Abb Al16-22-00-81 24v Dc Contactor

US $45.00

Fremont, California, United States
Jan 29th

Open on mobile:
QR code

BRAND NEW!! NEVER USED! DON'T TAKE A CHANCE ON A "USED" 24V DC Contactor ITEM IS IN ORIGINAL FACTORY BOX! General Information Extended Product Type: AL16-22-00 24V DC Product ID: 1SBL183501R8100 EAN: 3471522279811 Catalog Description: AL16-22-00 24V DC Contactor Long Description: AL16 4-pole contactors are mainly used for controlling non-inductive or slightly inductive loads (i.e. resistance furnaces...) and generally for controlling power circuits up to 690 V AC and 440 V DC. The contactors can also be used for many other applications such lighting... The AL... series 4-pole contactors are of the block type design. - Main poles and auxiliary contact blocks: 2 N.O. + 2 N.C. main poles, front and side-mounted add-on auxiliary contact blocks - Control circuit: DC operated with solid core magnet circuit. The polarity on the coil terminals (A1+ and A2-) must be respected - Accessories: a wide range of accessories is available. AL... contactors are fitted with low consumption DC coils and are suitable for a direct control by PLC outputs Environmental Ambient Air Temperature: Near Contactor for Operation in Free Air (0.85 - 1.1 Uc) -40 ... +55 °C Near Contactor for Operation in Free Air (Uc) -40 ... +70 °C Close to Contactor for Storage -60 ... +80 °C Maximum Operating Altitude Permissible: 3000 m Resistance to Shock acc. to IEC 60068-2-27: Closed, Shock Direction: A 20 g Open, Shock Direction: A 10 g Closed, Shock Direction: B1 15 g Open, Shock Direction: B1 5 g Shock Direction: B2 10 g Closed, Shock Direction: C1 20 g Open, Shock Direction: C1 8 g Closed, Shock Direction: C2 14 g Open, Shock Direction: C2 8 g RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment Technical Rated Operational Current AC-1 (Ie): (690V) 40°C 30 A (690V) 55°C 27 A (690V) 70°C 23 A Number of Main Contacts NO: 2 Number of Main Contacts NC: 2 Number of Auxiliary Contacts NO: 0 Number of Auxiliary Contacts NC: 0 Rated Control Circuit Voltage (Uc): DC Operation 24 V Terminal Type: Screw Terminals Coil Consumption: Average Holding Value, from Warm State 3 W Average Pull-in Value, from Cold State 3 W Certificates and Declarations (Document Number) CCC Certificate: CCC_2004010304112227 Declaration of Conformity - CE: 1SBD250842C4000 GOST Certificate: GOST_POCCFRME77B07175 RoHS Information: 1SBD350051R1000

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ABB
MPN	AL16-22-00 24V DC Contactor
Model	AL16-22-00-81
Country/Region of Manufacture	France
