ABBA (Comtop) PRECISION ROLLED BALLSCREW, 2350mm LONG, 10mm PITCH, 25mm DIA ~NEW, US $225.00 – Picture 0
ABBA (Comtop) PRECISION ROLLED BALLSCREW, 2350mm LONG, 10mm PITCH, 25mm DIA ~NEW, US $225.00 – Picture 0

Abba (comtop) Precision Rolled Ballscrew, 2350mm Long, 10mm Pitch, 25mm Dia ~new

US $225.00

  • Healdsburg, California, United States
  • Jan 29th
Open on mobile:
QR code
Comtop is the formal name for ABBA ballscrew. This auction is for ONE ball screw only! I bought this for a 4'x8' router project, but I never got to it, so I am selling the parts now. Specifications: -manufacturer: ABBA (in Comtop catalog they also refer to ABBA as brand, see attached image) -precision rolled -overall length: 2350mm (92.52") -threaded length: 2190mm (86.22") -travel: 2105mm (82.89") -pitch: 10mm -accuracy grade: C7 (maybe C6 but I do not remember well so sell them as C7) -outer diameter: 25mm -nut total length: 85mm -nut body diameter: 40mm -nut flange diameter: 62mm -nut flange thickness: 12mm -nut flat size: 48mm -screw holes on the nut flange: 6 screw holes for M6 screws -end machining (same on both ends): 20mm diameter for bearings- 38mm long, M20x1 thread for bearing nut- 15mm long, 17mm diameter for coupler - 25mm long. Both ends are machined for fixed end support but one end could be mounted as floating end. SORRY NO INTERNATIONAL TRANSACTIONS ALSO NO SHIPPING LARGE ITEM TO P.O. BOXES, ALASKA,HAWAII APO or FPO.WILL ONLY SHIP TO THE LOWER 48 STATES . Thank you for looking.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Comtop
Country/Region of Manufacture Taiwan
