Ac85-242v 0-70°c Thermostat Temperature Control Temp Controller Thermometer

US $64.30

Guangzhou ,Guangdong, China
Jan 29th

Open on mobile:
QR code

welcome to our shop! Description AC85-242V 0-70° C WST-D2 Automatic Switching Hot and cold Smart Thermostat Intelligent temperature controller temp control Thermometer #1400175 The instrument Each button's function clearly By Relay on and off Realize Automatic control Controller According to changes in temperature conditions Automatically shut down or start control device Parameters: Temperature measurement range: 0 ℃ ~ 70 ℃ Sensor: NTC10K B3435 Resolution: 0.5 ℃ Control accuracy: 1 ℃ Output Type: Relay (contact capacity 250V, 10A) Case size: 87mm x 135mm x 45mm Operating voltage: AC85 ~ 242V 50Hz/60Hz Control Type: Automatic hot and cold / Heating / coolingWST-D2:Can set the functions of the two outlets,Can the same function,To the contrary function; Can automatically select the device according to the change management,Automatic open heating temperature is too low,High temperature automatically open cooling (fan control, etc.). Parameter setting: After the instrument Powered Sequentially displayed 0-9, Detection monitor is normal or not ,then enter the system working state, Measured value display, if you do not change the setting value Data is automatically credited to the original setting automatic control operation. 2) Change the accused temperature settings: in Powered state ,Long press the SET button, Enter the menu mode, Adjusted according to the corresponding parameters, Press the "up" or "down" button to change the setting, "Up" is used to increase the temperature setting, "Down" is used to reduce the temperature setting, Finally, press the "SET" to adjust data memory, Temperature controller returns to the operating state control, If the data set is not confirmed by “SET,” The system default back to work after 10 seconds automatically. 3) actual use, do not let the lower limit higher than the upper limit. 4) Temperature sensor short circuit, Circuit fault tips Err. Installation: the ambient temperature of the instrument must be maintained between -5 ℃ ~ +65 ℃, Instrument shall be placed No humidity and high pressure occasion To ventilation for easy cooling Wiring: the need to control the device plugged into the socket on the panel, Instrument power supply must be marked in accordance with the specifications of some power equipment.(Note: The meter on the left of the first group, the right for the second group) Symbol Item Content Factory setting Unit H1 The first group Temperature upper limit 1-70 32 ℃ L1 The first group Temperature Lower limit 1-70 30 ℃ H2 The second group Temperature upper limit 1-70 35 ℃ L2 The second group Temperature Lower limit 1-70 31 ℃ HC1 The first set of cooling / heating Switching 00-70 00 * HC2 The second set of cooling / heating Switching 00-70 00 * Note: HC1, HC2 heating / cooling state switching data :00 = heating state, 01 = cooling state, other value = do not output packing including: 1X temperature controller Payment We only accept payments via paypal. All payments must be prepaid, no Cash and COD payment. We will ship the item to the address on your paypal payment notice, Please confirm your shipping address in the PayPal Account. If you have any problem about payment , please contact us. Delivery details Item will be shipped within 3 working days after full payment is received. We ship worldwide with flat rate shipping by post Air mail, the shipment usually takes 15-45 business days . We can also provide express post by EMS(5-8 days) or UPS(4-5 days). The cost is higher than standard postage, extra shipping fees is needed. if you need express post please contact us ! About us We will leave positive feedback to buyer as soon as buyer pays for the item .Your satisfaction is our first priority. Please leave us positive feedback upon satisfaction of the item. Please email us before leaving negative and neutral feedback. We will try our best to solve the issue. We will leave positive feedback to buyer as soon as buyer pays for the item . Contact us we do try respond as quickly as possible. Due to time zone difference, please allow 12~24 hours to get your mail replied. If you have any questions, Please contact with us via ebay message or our customer service e-mail .thanks for your buying ,wishes you have a happy shopping from our shop ! Engineered for professional eBay sellers! On Nov-26-14 at 13:33:58 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	product name	digital Thermostat
Resolution	0.5 °C
module name	temperature controller
Control accuracy	1 °C
Temperature measurement range	0 °C ~ 70 °C
Output Type	Relay (contact capacity 250V, 10A)
Sensor	NTC10K B3435
Operating voltage	AC85 ~ 242V 50Hz/60Hz
