Access Control Semi-auto Vertical Tripod Turnstile For Entrance Control System

US $570.00

Hongkong, China
Jan 30th

Open on mobile:
QR code

We put this advertisement specially for integrator and installer, if you have large amount demand, we could offer better price for bulk purchase! Store categories Item description Access Control Semi-Auto Vertical Tripod Turnstile for Entrance Control System Technical Specification : Description Parameter Power Supply Input AC110/220V±10%, 50HZ 200W Working Voltage 24V DC Power Consumption During Idle 10W Power Consumption During Operation 150W Passage Width 600mm Response Time 0.3 second Pass Speed 25person per minute Housing/Arm Stainless Steel Internal Mechanism Mild Steel Arm Disc Alloy Chromed Protection Level: IP45 Working Temperature: -30°C~50°C Electro-magnetic drive: 24V DC Thickness of Ply : 1.5mm (Standard)?304# Polishing: Brushed surface (Standard) / Polishing surface Weight: About 42KG Size: 420mm(L)x330mm(W)x980mm(H) Mechanical life: Two million Arm Length: 500mm Arm Diameter: 38mm (Standard) Max Tolerance of Arm: 60KG Diving Force of Arm: 3KG Relative Humidity (RH): 5%-90%(without concretion) Interface: RS485 Control I/O: ±12V electrical level signal or DC12V pulse signal of pulse width >= 100ms Features: ? Mechanical drive unit with solenoid locking mechanism eliminate the use of expensive electric motor and reduce maintenance cost. ? If arm rotated more than half, it will auto-rotate to the next idle position. If arm rotated less than half, it will auto-rotate back to the current idle position. ? Built in adjustable tensioner to control rotation force to minimize over rotation. Arm just need to be pushed lightly to rotate therefore even elderly or children are able to use the turnstile. ? Turnstile can be configured to be bi-directional or uni-directional. Housing is locked with special key to avoid tampering. ?When power off, the arm will be dropped down (optional set free passage when power off) to the request of fire protection. When power on, the arm can lift by hand. ? Emergency configuration: the tripod will drop automatically by power off to provide a clear walkway for escape in the event of an emergency ? Control panel with count and LED digital function. Traffic-light: A Red Cross symbol will illuminate to indicate the unit is not available for pass, and a green arrow indicate the direction of allowable passing ? It can be used for intelligent control and management of the passage after equipped with diffent access control system. ?A valid lock action can allow one passage at one time. It will lock automatically if passage through turnstile is not completed within pre-set time, the set time(from 2-60 seconds, by default, it is 10 seconds) can be set up with the built-in small keyboard or software. ?Self-recovery function: the machine will recovery automatically with invalid counting if passage is not completed within pre-set time (5 seconds default, adjustable by software) Applications: ? Vertical Tripod Turnstile is an electro mechanical turnstiles. Its unique mechanical drive design allow the arm to be pushed effortlessly and auto-rotate back without any expensive electric motor ?Vertical Tripod Turnstile can effectively control high volume human traffic ( up to 25 person per minutes ) while still maintaining a welcoming atmosphere. They can easily be integrated with any electronic system for ticketing, access control or time attendance. ?Vertical Tripod Turnstile is suitable for both indoor and outdoor(Shed). They are optimized economical solution for railway, bus station, factory, colleges, commercial building, library, stadium, game park, hotel, super market, bank and etc. Turnstile accessories: ? Turnstile Mechanism (semi-auto) ? Turnstile housing (304# Stainless steel at 1.5MM) ? Turnstile Control Board ? Turnstile Supply ? Turnstile Traffic Indicator(double direction) ? Turnstile Passage Status Lights Payment 1.We accept payment via PayPal. 2,Payment must be received within 7 business days of auction closing. 3.All major credit cards are accepted through our secure payment processor PayPal. Shipping 1.The product will be shipped via Express logistics(default), the period is about 3 - 6 working days. 2.If you order more items, or the package of Vertical Tripod Turnstiles is more than 1 cubic meters, then it should be shipped by sea freight, customer who want to buy please contact us to check exact the cost of sea freight(we need your specified sea port), 3. we put this advertisement specially for integrator or installer, if you have large amount demand, we could offer better price for bulk purchase. Notice: the delivery period of?sea freight normally takes 30-40 days. Terms & Conditions 1.Any durty fee will be paid by the buyers. 2.We have warranty of 1 year after installation, after 1 year, we could provide spare parts at basic cost, according to our experience, the earliest hardware system operated on market has been running for about 8 years and still works very well, so we are confident to sell this system. 3.Due to it is international shipment and will be expensive to return the goods to our factory(even the fault rate is very low), you need to provide Videos, pictures and report if you found the turnstiles is defective(such as a scratch or a dent but still can work) or not working at all, we would also take videos, pictures as proof before delivery, in case any man made mistake during installation, we need to discuss certain percentage compensation or full refund(if it is our fault), or replace some new spare parts(buyer pay for the shipping cost, because you don't need to pay returning cost any more). © cn_resources Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country/Region of Manufacture

China
