Acculign Benchmark Gauge Set Turbo Machine Allignment Tool

US $1300

Madison, Connecticut, United States
Jun 12th

Open on mobile:
QR code

You are looking at a Acculign Turbo Machinery BASIC BENCHMARK GAUGE SET Benchmark gauges are specifically designed for conducting on-line checks of turbomachinery alignment. The basic benchmark gauge set consists of a telescoping column with an electronic digital readout, six extensions, a 25" standard, and an inclinometer. The digital readout uses a single 1.5 volt size SR44 battery (type and size commonly used in electronic calculators and cameras). Expected battery life is 2 years. A spare battery is furnished. The benchmark gauge itself is spring-loaded with spherical seats at either end to match the spherical benchmarks that are mounted on the equipment. The gauge is self-supporting when placed between pairs of benchmarks. The range of the benchmark gauge, without extensions, is 25" to 30". The six extensions give the tool a total range of 25" to 60" in increments of 0.001". The standard and the extensions are constructed of Invar. The low coefficient of thermal expansion of this material greatly reduces measurement errors resulting from thermal expansion of the tool itself. The standard and the extensions are manufactured to an overall accuracy of 0.001" in length. Exposed portions of the tool, including spherical seats, are stainless steel. The gauge set is packaged in a durable ABS plastic case. Overall dimensions 38" x 14" x 5", weight 28 pounds. We will ship this allignment tool for 40.00 S/H anywhere in the lower 48 states thanks for looking and good luck.
