Acterna Jdsu Edt-135 E1 And Data Circuit Tester Edt135 Edt 135

US $3,495.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Acterna EDT-135 E1 and Data Tester (BC# 15420) (2) BNC To BNC Cables AC Adapter/Charger Power Cord Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Acterna EDT-135 E1 and Data Tester This powerful tester includes a full set of measurements to install, commission and troubleshoot E1 and data circuits, along with the services that run over them. Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Acterna EDT-135 E1 and Data Tester Applications Installing, commissioning and maintaining E1 circuits and multiplexers Commissioning and maintainng datacom and V.24 modem circuits Commissioning Frame Relay services Installing and maintaining GSM circuits This powerful tester includes a full set of measurements to install, commission and troubleshoot E1 and data circuits, along with the services that run over them. Installation tests require basic out-of-service Bit Error Rate (BER) testing to assess cabling integrity. Full commissioning requires extended BER testing to international standards, as well as stress testing and complete assessment of link performance with respect to error and alarm reporting. For successful maintenance, rapid identification of the current line status is critical to the speedy resolution of problems. Specific services (such as Frame Relay and GSM) have their own testing requirements, and require a tailored solution to ensure satisfactory operation. Functions E1 and n x 64k BERT with Autoconfigure and G.821, G.826 and M.2100 testing Clear OK/Status Page Multi-interface capability: V.24/RS232, V.11/X.24, V.35, V.36/RS449, G.703 (2048/704kbit/s), G.703 co-directional Frame Relay commissioning tools, turn-up, PING and Fox Multiplexer tests include MUX/ DEMUX and A-D/D-A measurements Special sub-rates (HCM, X.50, V.110) Features such as Autoconfigure and the 'Big OK' result screen make it easy to use with a minimum of training. Quality of Service can be measured with G.821, G.826 or M.2100. E1 signal quality measurements include jitter, level and pulse shape. Datacom interface control signals can be monitored and set. V.24 modem tests include dial-up, autoanswer, distortion measurement and BER. Other important features include round trip delay measurements on E1 and datacom circuits and E1 drop and insert. Comprehensive service testing is possible using dedicated options. Easy to Use The EDT-135 has been designed with the user in mind. As well as being lightweight and comfortable to hold and carry, all testers feature large LCD screens with integral backlight for the most demanding testing environments. If you wish to self-support the tester, the integral two-position backstand/carry handle can easily be folded out, and can also be configured to suspend the instrument for hands-free viewing. Test results are displayed in a concise, graphical format with our recognised 'Big OK' when no errors are present. Multiple language support is standard and comprehensive alarm and error status LEDs give clear indication of problems, even from a distance. And, as you'd expect, all results data can be stored for later analysis or printed to an external printer with a single keypress. Autoconfigure The Autoconfigure feature greatly simplifies instrument set-up. A test can be started on framed or unframed traffic using just 2 key-presses. For a framed signal, the instrument can determine the framing type, timeslot allocation and test pattern type. Gelbrich Synchronization The patented Gelbrich Synchronization method enables synchronization on a test pattern to be maintained and accurate BER measurement to be made even in the presence of rapid bursts of errors. It also enables differentiation to be made between bit slips and bit errors. Result Storage and Printing The EDT-135 has 8 test memories for the storage of text and histogram results, for viewing or printing at a later time. Printing of results is supported through the serial port. A setup screen enables the instrument to be set up for a range of printers. Programmable Timers The instrument can be programmed to start a test at a specified date and time for a selectable duration. Remote Operation The instrument is compatible with the DTM-32 remote operation solution. Battery/Mains Operation 8-10 hour battery life using rechargeable and exchangeable batteries. Long duration testing can be achieved with a.c. mains power. Software Option Download The testing capability of the EDT-135 can be greatly extended by downloading a range of software options. Applicable options include Signal Level Measurement, Pulse Shape Analysis, Jitter, Large Frequency Offset of Transmit Clock, Frame Relay, HCM, GSM, Enhanced Datacom Tests and Voice Channel Noise Measurement. Instrument Applications E1 Service Turn-up Availability and performance of an E1 link can be established using either an intrusive or a non-intrusive test. The EDT-135 can be connected via 75/120 connectors using Hi-Z termination or at a protected monitor point. A typical simple E1 test will take no longer than 30 seconds, the OK screen quickly indicates when an E1 service is present and error-free. G.826/M.2100 test sequences can then be run, and the results displayed, stored and printed. n x 64kbit/s Timeslot Analysis 64kbit/s timeslots are grouped within the E1 frame to give endcustomers intermediate data speeds such as 128 or 256kbit/s. The EDT-135 can perform BER analysis on bundles of n x 64kbit/s slots, and drop and insertn x 64 kbit/s to an external protocol analyser via V.11. G.826 and M.2100 Analysis G.826 is the ITU-T recommendation for error performance of international digital paths at or above the Primary Rate. The complementary M.21xx series permits rigorous testing of PDH links but in shorter time periods. Both methods are included as standard software modules in the EDT-135 tester. The following screens illustrate the summary results from G.826 and M.2100 tests. E1 Service Troubleshooting An extended bit error test will determine whether a periodic fault is causing problems. Electrical equipment such as airconditioning may cause problems at regular times in the day. Error histograms make it possible to identify external events which can be isolated as causes of the problem. Faults in an E1 line can be caused by low signal, pulse distortion or jitter. If loss of signal (LOS) or similar alarms are indicated by a network element, level measurement and pulse shape tests can easily be made to determine where the fault exists in a link, by examining the signal condition. A low or distorted signal received by a network element would indicate a problem with the preceding element or the interconnecting cables. Excessive jitter can result in bit errors, loss of frame synchronization or similar faults. Where these faults exist, jitter measurements can be performed to determine if jitter is the cause, and also to discover at which point in the system the jitter reaches unacceptable levels. Technical Specifications Generator/ Receiver Interfaces: G.703 Outputs: Balanced 3 pin CF connector Unbalanced BNC connector G.703 Test Modes: RX Framing: PCM30, PCM30CRC, PCM31, PCM31CRC, or Unframed G.703 line code: HDB3, AMI, co-directional V.11 drop: 1 x 64kbit/s, n x 64kbit/s RX/TX As RX plus: BER Test pattern generation: Single timeslot n x 64kbit/s timeslots V.11 Drop/Insert: Drop and/or Insert n x 64kbit/s timeslots Drop and Insert 1 timeslot Programmable Si, Sa, A and E bits and NMFAS Through Mode As RX/TX plus Drop and/or Insert via V.11 Round Trip Delay Framed and Unframed 2Mbit/s MUX and DEMUX Testing Receiver and transmitter as for RX/TX modeUnframed TX and RX on V interfaces or G.703 co-directional Framed Monitor Monitor and display of: FAS, NFAS, MFAS, NMFAS, and CRC MFAS words 8-bit digital code word in any selected timeslot, CAS status of all 30 channels with idle/busy indication Level and Frequency Digital generation/measurement of sinusoidal signals in a timeslot. (A-law coding to ITU-T Rec. G.711) X.50 Test Modes Interfaces: V.11, V.35, V.36, RS449 and G.703 co-directional Test Patterns PRBS: 26-1, 29-1, 211-1, 215-1, Alternating 1 and 0s, All 1s, All 0s, 8 and 16 bit programmable word Error Injection Bit, Code, FAS, CRC errors: Single, ratio or frequency Clocking G.703 transmit clock source 2048kbit/s and co-dir: Internal, External, From RX Error and Alarm Indication LEDs: 2 summary, 14 alarm/error, option, low battery Printer and Remote Operation Interface: V.24, DTE, Async Baud rates: 300, 600, 1200, 2400, 9600, 19200, 38400 Front Panel Display: 42 character x 16 line LCD, LED back-light Keyboard: Numerical keypad, 4 Cursor, 2 Contrast,Main Menu, 6 Softkeys, Alt, On and Off Stores/Memory 8 test result memories and 8 configuration stores Self Check Comprehensive self check at power on Languages English, German, French, Spanish, Italian, Turkish and Portuguese Power Supply External supply: External mains charger Rechargeable batteries: 8 to 10 hours operating time Battery low: warning before auto switch off Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. --> This item is subject to a FIXED SHIPPING price. This means that the shipping fee will be the displayed amount for all ship-to destinations shown. This item is eligible for pickup unless otherwise stated. We do not ship to any destinations that are not specified here. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do/do not cover this cost for all of our US customers. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept payment transactions via our online checkout system! Our checkout process is designed that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through our online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hrs upon receipt of payment from the winning bidder. A Shipment Tracking number will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Terms: All transactions are final. Winning bidder assumes all risk of liability with respect to the purchase of the product. Thank you WE ACCEPT ALL MAJOR CREDIT CARDS Put your listings on autopilot with Kyozou eBay Listing Management Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	Acterna
Model	EDT-135
