Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator, US $80.50 – Picture 0
Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator, US $80.50 – Picture 0

Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator

US $80.50

  • Swanton, Vermont, United States
  • Aug 6th
Open on mobile:
QR code
Description Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator Offers high accuracy Comes in 25 mm stroke length Provides long life brushless motor Gear Ratio: 49:1 Temperature Rise: 80 °C Max The Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator is a complete, self-contained linear motion device. It comes in a 25 mm stroke length option to allow these to fit for a wide variety of applications. The brushless stepper design makes the P8-ST one of the longest-life actuators. The P8 stepper is designed to push or pull a load axially along its full stroke length. The speed of travel is determined by the step frequency, and maximum force by the current applied. When power is removed the actuator will hold its position unless the applied load exceeds the back drive force. Actuators should be tested in each specific application to determine their effective life under those loading conditions and environment. Specifications Stroke: 25 mm Maximum Side Load: ≈ 0.10 *Maximum Force Gear Ratio: 49:1 Backdrive Force: 9 N (No power) | >30 N (Power applied) Temperature Rise: 80 °C Max Input Voltage: 0-4.2 VDC Max Current (per phase): 256mA Operating Temperature: -10 to +40 °C Audible Noise: < 40 dB at 45 cm low noise settings Ingress Protection: IP-54 Mechanical Backlash: < 0.5 mm Inductance (per phase): 4.5 mH at 1 khz Resistance (per phase): 15 ohm Maximum Duty Cycle: 100% Maximum Static Load: 200 N Mass: 20 g What's Included 1 x Actuonix 25mm 49:1 P8 Micro Linear Stepper Actuator Dimensions Size Stroke length: 25 mm Closed Length hole to hole: 60 mm Full Step: ~0.006 mm
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Actuonix
Type Actuonix
MPN P8-ST-25-49
UPC Does not apply
