Actuonix L12 Linear Actuator 30mm 50:1 12v Analog

US $92.00

Swanton, Vermont, United States
Jul 14th

Open on mobile:
QR code

Description Peak Power Point: 12N at 11mm/s Gear Ratio: 50:1 Max Speed (no load): 23mm/s Input Voltage: 12V Stall Current: 200ma at 12V Interface: Analog voltage Weight: 34g Actuonix's new L series of miniature actuators combine the best features of their existing micro actuator families into a highly flexible, configurable and compact platform with an optional sophisticated on-board controller. The first member of the L series, the Actuonix L12, is an axial design with a powerful drivetrain and a rectangular cross section for increased rigidity. But by far the most attractive feature of this actuator is the broad spectrum of available configurations. For more information on configuration options, please view the L12 Configuration Sheet. Control and Position Feedback : This actuator provides an analog position feedback signal that can be read by an external controller. While voltage is applied to the motor V+ and ground leads, the actuator extends. If the polarity of this voltage is reversed, the actuator retracts. Actuator stroke position may be monitored by providing any stable low and high reference voltages on leads 1 and 5, and then reading the position signal on lead 2. The voltage on lead 2 will vary linearly between the two reference voltages in proportion to the position of the actuator stroke. Dimensions Stroke: 30 mm (0.2 mm accuracy) Dimensions: 90 x 18 x 15 mm Weight: 34 g

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Actuonix
Type	Actuonix
MPN	L12-30-50-12-P
UPC	Does not apply
