Actuonix T16 Micro Linear Actuator, 100mm, 22:1, 12V w/ Potentiometer Feedback, US $103.50 – Picture 0
Actuonix T16 Micro Linear Actuator, 100mm, 22:1, 12V w/ Potentiometer Feedback, US $103.50 – Picture 0

Actuonix T16 Micro Linear Actuator, 100mm, 22:1, 12v W/ Potentiometer Feedback

US $103.50

  • Swanton, Vermont, United States
  • Aug 30th
Open on mobile:
QR code
Description Gear ratio: 22:1 Stroke: 100mm Max Speed (no load): 46mm/s Input voltage: 0-15 VDC, Rated at 12VDC Stall current: 1000mA @ 12V Comes with Potentiometer Feedback The Actuonix T16 Micro Linear Actuator, 100mm, 22:1, 12V w/ Potentiometer Feedback enables a new generation of motion-enabled designs. They boast the same side by side design and versatile planetary gearbox as P16 line. The T16 miniature track actuators offer capabilities that have never before been combined in a device of this size. These linear track actuators are a superior alternative to designing your own custom push/pull mechanisms. As with other "P" series actuators, the T16-P does not have a built in controller, but does provide an analog position feedback signal that can be input to an external controller. The "P" series can be used with Linear Actuator Control Board (LAC) to give the "P" series the ability to be controlled with USB (via Configuration Utility Software), 0.5v, 4-20mA, RC Servo or PWM. On-board adjustment of speed, sensitivity and stroke limits are available via the LAC. The "P" series are available in 12V only. Specifications Feedback Linearity: Less than 2.00% Input Voltage: 0-15 VDC. Rated at 12VDC. Stall Current: 1000mA @ 12V Operating Temp: -10C to +50C Audible Noise: 62 dB @ 45cm Ingress Protection: None Mechanical Backlash: 0.3mm Limit Switches (-S): Max. Current Leakage: 8uA Maximum Static Force: 500N Maximum Duty Cycle: 20% Stroke Repeatability (-P/LAC): 0.4mm Potentiometer: 11kΩ 50% Gear Peak Power Point: 40N @26mm/s Peak Efficiency Point: 25N @34mm/s Max Speed (no load): 46mm/s Max Force ( < Stall ): 50N Back Drive Force: 75N
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Actuonix
Type Actuonix
MPN T16-100-22-12-P
UPC 678835001686
EAN 0678835001686
