Actuonix T16 Mini Linear Actuator, 200mm, 64:1, 12v W/ Limit Switches

US $92.00

Swanton, Vermont, United States
Jul 29th

Open on mobile:
QR code

Description Peak Power Point: 80N at 9mm/s T16 mini linear actuator with limit switches Max speed: 18mm/s Stroke lengths of 200mm Gear Ratio if 64:1 Max. Operating Voltage a 12V unit The Actuonix T16 Mini Linear Actuator, 300mm, 256:1, 12V w/ Limit Switches enables a new generation of motion enabled product designs, with capabilities that have never before been combined in a device of this size. These linear track actuators are a superior alternative to designing your own push/pull mechanisms. Built on the same platform as the proven P16, the T16-S actuators are complete, self-contained linear motion devices with end of stroke limit switches for simple two position automation. The track design makes the T16 significantly shorter than the same stroke length P16, since instead of an extending shaft, a sliding mount is provided. The sliding mount also significantly increases the maximum side load specification. Specifications Feedback Linearity: Less than 2.00% Input Voltage: 0-15 VDC. Rated at 12VDC. Stall Current: 1000mA @ 12V Operating Temp: -10C to +50C Audible Noise: 62 dB @ 45cm Ingress Protection: None Mechanical Backlash: 0.3mm Limit Switches (-S): Max. Current Leakage: 8uA Maximum Static Force: 500N Maximum Duty Cycle: 20% Stroke Repeatability (-P/LAC): 0.8mm Potentiometer: 23kΩ 50% Gear Peak Power Point: 80N @9mm/s Peak Efficiency Point: 40N @14mm/s Max Speed (no load): 18mm/s Max Force ( < Stall ): 90N Back Drive Force: 200N

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Actuonix
Type	Actuonix
MPN	T16-200-64-12-S
UPC	Does not apply
