Ad9834 Direct Digital Synthesizer, Low Power Dds, Data Acquisition, 20-tssop

US $9.99

Oceanside, California, United States
Jun 9th

Open on mobile:
QR code

Direct Digital Synthesizer AD9834CRUZ, +2.3 V to +5.5 V, Low Power (20 mW), 75 MHz Complete DDS, 20 Pin TSSOP, Quantity 1, Analog Devices The AD9834 is a 75 MHz low power DDS device capable of producing high performance sine and triangular outputs. It also has an on-board comparator that allows a square wave to be produced for clock generation. Consuming only 20 mW of power at 3 V makes the AD9834 an ideal candidate for power-sensitive applications. Capability for phase modulation and frequency modulation is provided. The frequency registers are 28 bits; with a 75 MHz clock rate, resolution of 0.28 Hz can be achieved. Similarly, with a 1 MHz clock rate, the AD9834 can be tuned to 0.004 Hz resolution. Frequency and phase modulation are affected by loading registers through the serial interface and toggling the registers using software or the FSELECT pin and PSELECT pin, respectively. The AD9834 is written to using a 3-wire serial interface. This serial interface operates at clock rates up to 40 MHz and is compatible with DSP and microcontroller standards. The device operates with a power supply from 2.3 V to 5.5 V. The analog and digital sections are independent and can be run from different power supplies, for example, AVDD can equal 5 V with DVDD equal to 3 V. Features: Narrow-band SFDR >72 dB 2.3 V to 5.5 V power supply Output frequency up to 37.5 MHz Sine output/triangular output On-board comparator 20 mW power consumption at 3 V Applications: Frequency stimulus/waveform generation Frequency phase tuning and modulation Low power RF/communications systems Liquid and gas flow measurement Sensory applications: proximity, motion, and defect detection Test and medical equipment Click here to see the datasheet. Quantity 1 ....... New Part !!!!! Be sure to add me to your favorites list!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Analog Devices
Country of Manufacture	United States
Model	Synthesizer
Type	ICs & Processors
MPN	AD9834
Circuit Type	DDS
Country/Region of Manufacture	United States
Firmware	Frequency Generator
