Ad9959 4 Channel 200mhz Dds Signal Generator 500msps Update Ad9854 Adi Software

US $106.80

shenzhen, China
Jan 29th

Open on mobile:
QR code

AD9959 4 Channel 200MHz DDS Signal Generator 500MSPS Update AD9854 ADI Software Description AD9959 4 Channel 200MHz DDS Signal Generator 500MSPS Update AD9854 ADI Software DESCRIPTION Features: 1, AD9959: 4channel, 500MSPS, the highest 200M sine wave output; 2, 4-channel independent of frequency, amplitude and phase adjustable; 3,32-bit accumulator, the frequency resolution is better than 0.12HZ; 4,14-bit phase register, phase resolution 0.022 degrees; 5,10-bit amplitude register, fine adjustable amplitude 1024; 6,2 bands, 4 bands, 8 bands, 16 bands, ASK, PSK, FSK modulation powerful features; 7, linear frequency, amplitude and phase sweep function; 8, independently programmable DAC output current; 9, high-speed SPI communication; 10, ADI is fully compatible with the original PC software, control panel USB2.0 interface, easy to use; (Note: Driver support XP, WIN7 32 bit addition WIN7 64 bit and WIN8 may not support;) 11, low power consumption, etc. victory AD9854 chip, 4-channel 200M Signal tone output, power consumption of only 580mW; Application: 1, the local oscillator; 2, test equipment; 3, the synchronization clock frequency signal source; 4, AD9959 learning modules; Specifications: 1, controlled via USB (5V power supply),AD9959 module uses +-5V power supply; (Note: Because the positive and negative terminals of load imbalance, can not use switching power supply + - power supply, this may lead to the negative terminal of the voltage is too high;) 2, the use of high-speed operational amplifier coupled to the output, the impedance matching, post 200M filter; 3, the output frequency of 0 --- 200M, 0.12HZ resolution; 4, the output amplitude 0-2VPP @ 1M impedance,0 - 1VPP @ 50 in Europe, Amplitude flatness :0-100M @ 0.4dB 100M --- 150M @ 1dB flatness The magnitude of the amplitude can be achieved by 1024 PC software fine adjustable; 5, the independent phase adjustment, the fine phase resolution of 0.022, etc. IQ signal can be realized. include: 1PC AD9959 Module 1PC control module 1PC USB line 1PC row line Payment Payment : We accept paypal Credit card payments must be made through PayPal. We recommend you to sign for a PayPal account before bidding. We will Not take responsible on Customs duty if any Shipping time : Shipping time : If you haven't get your parcel within the expected date,Pls contact with us directly.We can ensure solve it for you .Pls trust us .We need your support. Thanks .Yours Sincerely. Country Shipping Time Refund or Resend 80% 12% 5% United States United Kingdom Australia /Canada 10-20 working days 25 working days 27 working days >27 working days Singapore Other Asia country 15-25 working days 28 working days 32 working days >32 working days Germany /France Austria /Netherland Poland 20-30 working days 33 working days 36 working days >36 working days Spain Russia 25-35 working days 37 working days 40 working days >40 working days Others 25-35 working days 37 working days 40 working days >40 working days Feedback Feedback : We would appreciate receiving your 5 stars positive feedback.If there's any dissatisfaction with your parcel ,pls contact with us before you leave the feedback .We can solve it for your perfectly.Thanks for your understanding and help. Return Policy 1. All items are checked and packed in good condition before dispatch. 2. If you find any defect in our items, please contact us within 14 days of receipt item. 3. Return items must not be used. 4. Buyer is responsible for all return shipping charges. We will return all your money except the shipping and handling fees or make exchange for you after we receive your return items. Please do not ship the item back to us without our confirmation. Thanks Contact us SHIPPING TERMS: Our work time is during 8:00 am -5:30 pm ,from Monday to Friday (GMT+8 ).We will post your order within 24 hours (Except some special orders ,such as the handmade case). Maybe we are out of office during the weekend, so pls wait for our reply patiently. We will reply all your problems as quickly as we can. Thanks for your understanding. Engineered for professional eBay sellers!
