Adapter Plate For Mounting a NEMA23 motor to a Metric Linear Slide (Frame 60mm), US $35.00 – Picture 0
Adapter Plate For Mounting a NEMA23 motor to a Metric Linear Slide (Frame 60mm), US $35.00 – Picture 0

Adapter Plate For Mounting A Nema23 Motor To A Metric Linear Slide (frame 60mm)

US $35.00

  • North Hollywood, California, United States
  • Jan 29th
Open on mobile:
QR code
Adapter Plate For Mounting a NEMA23 motor to a Metric Linear Slide (Frame 60mm) Adapter Plate For Mounting a NEMA23 motor to a Metric Slide (Frame 60mm)   Picture #1 – Show the NEMA23 Motor mounted to a metric slide via an adapter plate. Picture #2 – Show the initial metric – Frame 60mm motor – mounted to a metric linear slide. Picture #3  -  Show the mounting area at the end of an existing metric linear slide slide Picture #4 – The adapter plate is mounted and ready to receive a NEMA23 motor. Picture #5 – You can see here the plate dimensions with distances between mounting holes.   It is not possible to mount directly a NEMA23 motor to a slide designed to receive a 60mm frame motor. You will notice the NEMA23 motor is mounted at 45 degree. Four holes are provided for the NEMA23, the user will choose the desired threading. Because NEMA system is an American Standard the mounting holes for the NEMA23 motor are ready to receive a 10-32 threading.   Material – 6061 Aluminum Approx. 4.6mm thick   The linear slide and the motors shown in the above pictures are not included in the auction. You will receive the adapter plate shown in the last picture. See my other listings for more great items! For payment we accept PayPal and we ship only to a certified address.  Shipping $4.50  United States via USPS First Class Shipping. Shipping outside US $12.50 USPS First Class International txzj pxzj6565 txzj42 txzj91
