Adg409abr Analog Devices Lc2mos 4-/8-channel High Performance Analog Multiplexer

US $1.55

Huntington Beach, California, United States
Jun 9th

Open on mobile:
QR code

LC2MOS 4-/8-Channel High Performance Analog Multiplexers Mfr: Analog Device Part: ADG409ABR = 16pin SOIC Quantity: 1 piece, Cut tape ESD Shield Protective Sealed Packaging. PLEASE SEE OUR OTHER AUCTIONS FOR ADG408ABR APPLICATIONS: Audio and video routing Automatic test equipment Data acquisition systems Battery-powered systems Sample-and-hold systems Communication systems FEATURES: 44 V supply maximum ratings V SS to V DD analog signal range Low on resistance (100 ? maximum) Low power (I SUPPLY < 75 ?A) Fast switching Break-before-make switching action Plug-in replacement for DG408/DG409 General Description: The ADG408/ADG409 are monolithic CMOS analog multiplexers comprising eight single channels and four differential channels, respectively. The ADG408 switches one of eight inputs to a common output as determined by the 3-bit binary address lines A0, A1, and A2. The ADG409 switches one of four differential inputs to a common differential output, as determined by the 2-bit binary address lines A0 and A1. An EN input on both devices is used to enable or disable the device. When the device is disabled, all channels are switched off. The ADG408/ADG409 are designed on an enhanced LC2MOS process that provides low power dissipation yet gives high switching speed and low on resistance. Each channel conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. All channels exhibit break- before-make switching action, preventing momentary shorting when switching channels. Inherent in the design is low charge injection for minimum transients when switching the digital inputs. The ADG408/ADG409 are improved replacements for the DG408/DG409 analog multiplexers. FREE! Sellers: Add a FREE map to your listings. FREE! Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Analog Device
Country/Region of Manufacture	United States
Model	ADG409
Country of Manufacture	United States
MPN	ADG409ABR
ADG409	High Performance Analog Multiplexers 16pin SOIC
UPC	Does not apply
