Adira Cybelec 176 Ton Pm16030 Pls 10' Hydraulic Press Brake Cnc Crowning Y1y2r

US $15000

Mira Loma, California, United States
Jun 20th

Open on mobile:
QR code

NEW ADIRA PM-16030 10' HYDRAULIC PRESS BRAKE WITH CYBELEC DNC 880S CONTROL "R" AXIS, TOOLING, LIGHT CURTAIN AND CNC CONTROLLED CROWNING TABLE - The parallelism between beams during ascent and descent is ensured by two DNC controlled servo-valves (axes Y1 and Y2) - Two linear encoders located at both ram ends make the measuring of the ram position. The ram position in bending depth is independent from the working length - The bending depth (ram stopping point) is ensured by servo-valves controlled by the DNC - Easy adjustment of the bending depth under load over the plate to bend, with programmed 0.01 mm increments - Programming of the bending angle (0.01 degree resolution) - Programming of the ram tilting (Y1 different from Y2) to make cone bends - Calculation of the tonnage necessary to the required bending with the chosen tooling - Tooling library for the programming of the geometric characteristics of punches and dies - Long stroke, super-finished hydraulic cylinders, allowing for high versatility of use - Amply dimensioned throat depth, stroke and open height - Movable beam guided on 4 points with adjustable guides made of self-lubricated material and with maintenance free bearings - Sturdy monoblock frame, welded and stabilized - Electric and hydraulic protection against overloads - Compact hydraulic unit - Slow approach in Inch Mode for tooling adjustment. CUSTOMER CAN ARRANGE PICK UP OR WE CAN GET A QUOTE FOR YOU ON SHIPPING PLEASE CALL OUR SALES OFFICE IF YOU HAVE ANY QUESTIONS OR WOULD LIKE ADDITIONAL SPECIFICATIONS ON THIS UNIT 909 476 8007 Maximum Capacity 148 Tons Working Length 10’ Distance Between Housings 8.3’ Throat Depth 15.75” Maximum Stroke 10.2” Maximum Open Height 19.7” Approach Ram Speed 4.7” Per Second Working Ram Speed 0.275” Per Second Return Ram Speed 2.75” Per Second Motor Power 10.1 HP Voltage 480V / 3 Phase / 60Hz Approximate Weight 16,700 lbs. Overall Machine Length 14.1’ Overall Machine Width 5.8’ Overall Machine Height 9.3’ Back Gauge – X Axis Travel 24.6” Back Gauge – X Axis Speed 13.8” Per Second
