Adjust Ir Pyroelectric Infrared Ir Pir Motion Sensor Detector Module Hc-sr501

US $1.45

ShenZhen, China
Jan 30th

Open on mobile:
QR code

Description Product Type: HC--SR501 Body Sensor Module Operating voltage range: DC 4.5-20V Quiescent Current: <50uA Level output: High 3.3 V /Low 0V Trigger: L can not be repeated trigger/H can be repeated trigger(Default repeated trigger) Delay time: 5-200S(adjustable) the range is (0.xx second to tens of second) Block time: 2.5S(default)Can be made a range(0.xx to tens of seconds Board Dimensions: 32mm*24mm Angle Sensor: <100 ° cone angle Operation Temp: -15-+70 degrees Lens size sensor: Diameter:23mm(Default) Features: 1, the automatic sensor: to enter the sensor output range is high, people leave the sensor range of the automatic delay off high, output low. 2,the photosensitive control (optional, factory is not set) may set the photosensitive control during the day or light intensity without induction. 3, the temperature compensation (optional, factory is not set): In the summer when the ambient temperature rises to 30 ~ 32 ℃, slightly shorter detection range, temperature compensation can be used as a performance compensation. 4, two trigger mode: (can be selected by jumpers) a, can not repeat the trigger: the sensor output high, the delay time is over, the output will automatically become low from high; b, repeatable trigger: the sensor output high after the delay period, if the human body in its sensing range activities, its output will remain high until after the delay will be left high to low (sensor module review Measured activities of each body will be automatically extended after a delay time, and the final event of the delay time Starting point of time). 5, with induction blocking time (the default setting: 2.5S block time): sensor module, after each sensor output (high change Into a low level),you can set up a blockade followed by time period, in this time period the sensor does not accept any sensor signal. This feature can have a "sensor output time" and "blocking time" the interval between the work produced can be applied to detect the interval Products; also inhibit this function during load switching for a variety of interference. (This time can be set at zero seconds - Tens of seconds). 6, the working voltage range: the default voltage DC4.5V-20V. 7, micro-power consumption: static current "50 microamps, especially for battery-powered automatic control products. 8, the output high level signals: types of circuits can be easily and docking. Instructions: 1. Sensing module for about a minute after power initialization time, during the interval to the output module 0-3 times a minute in standby mode. 2. Should avoid direct lighting such as interference sources close the surface of the lens module so as to avoid the introduction of interference signal generator malfunction; use of the environment to avoid the flow of the wind, the wind sensor will also cause interference. 3. Sensor module using a dual probe, the probe's window is rectangular, dual (A per B million) in the direction of the ends of long, when the body passed from left to right or right to left when the reach the dual IR time, distance difference, the greater the difference, more sensitive sensors, when the body from the front to the probe or from top to bottom or from bottom to top direction passing, dual IR not detected changes in the distance, no difference value, the sensor insensitive or does not work; so the sensors should be installed dual direction of the probe with human activities as much as possible parallel to the direction of maximum to ensure that the body has been passed by the dual sensor probe. To increase the sensing range of angles, the module using a circular lens, the probe also makes sense on all four sides, but still higher than the upper and lower left and right direction of sensing range, sensitivity and strong, still as far as possible by the above installation requirements.VCC, trig (control side), echo (receiving end), GND 4. Dimensions and Adjustment: Note: The potentiometer clockwise to adjust the distance, sensing range increases (about 7 meters), on the contrary, sensing range decreases (about 3 meters).Delay adjustment potentiometer clockwise rotation, sensor delay longer (about 300S), the other hand, induction by the short delay (about 5S). 5. Applications a, Security Products b, the human body sensors toys c, the human body sensor lighting d, industrial automation and control, etc. It can automatically and quickly open various types of incandescent, fluorescent lamps, buzzer, automatic doors, electric fans,automatic washing machine and dryer Machines and other devices,is a hightech products. Especially suitable for enterprises, hotels, shopping malls, warehouses and family aisles, corridors and other sensitive Sense of region, or for the security zone automatic lighting, lighting and alarm systems. Package Included: 1 x Adjust IR Pyroelectric Infrared IR PIR Motion Sensor Detector Module HC-SR501 Recommended Products 10PCS Arduino NRF24L01+ 2.4GHz Wireless RF Transceiver Module New $8.60 Time left:8d 10h 10m New DHT11 Temperature and Relative Humidity Sensor Module for arduino $1.46 Time left:25d 3h 16m Ultrasonic Sensor Module HC-SR04 Distance Measuring Sensor for arduino SR04 $1.13 Time left:25d 4h 59m Wireless Serial 4 Pin Bluetooth RF Transceiver Module HC-06 RS232 With backplane $4.40 Time left:24d 7h 13m 2PCS,Arduino NRF24L01+ 2.4GHz Wireless Transceiver Module New $1.98 Time left:8d 9h 59m BMP180 Replace BMP085 Digital Barometric Pressure Sensor Board Module Arduino $2.20 Time left:23d 23h 55m New design 30A range Current Sensor Module ACS712 Module Arduino module $2.08 Time left:24d 3h 42m New Rain Water sensor water Level Sensor module Depth of Detection for Arduino $1.26 Time left:17d 20h 9m 5PCS Ultrasonic Sensor Module HC-SR04 Distance Measuring Sensor for arduino SR04 $6.13 Time left:23d 11h 34m Mini DC-DC Buck Converter Step Down Module Power Supply For aeromodelling $1.46 Time left:19d 8h 25m New IIC I2C Logic Level Converter Bi-Directional Module 5V to 3.3V For Arduino $1.40 Time left:5d 20h 19m 6pin FTDI FT232RL USB to Serial adapter module USB TO TTL RS232 Arduino Cable $7.13 Time left:12d 7h 51m Raindrops Detection sensor modue rain module weather module Humidity For Arduino $1.44 Time left:25d 20h 58m NRF24L01+PA+LNA SMA Antenna Wireless Transceiver communication module 2.4G 1100m $5.33 Time left:24d 2h 32m ADXL345 3-Axis Digital Acceleration of Gravity Tilt Module AVR ARM MCU Arduino $2.09 Time left:26d 3h 15m HMC5883L Triple Axis Compass Magnetometer Sensor Module For Arduino 3V-5V $1.43 Time left:19d 7h 21m Soil Hygrometer Detection Module Soil Moisture Sensor For arduino Smart car $1.35 Time left:21d 5h 54m Active Buzzer Alarm Module Sensor Beep for arduino smart car $1.98 Time left:2d 4h 41m 10PCS Ultrasonic Sensor Module HC-SR04 Distance Measuring Sensor for arduino $12.57 Time left:23d 11h 34m DHT21 AM2301 Digital Temperature Humidity Sensor module SHT11 SHT15 Arduino $3.98 Time left:2d 22h 49m LTC1871 DC-DC Step up Boost Module Power Supply 3.5V to 30V 100W LED Voltmeter $8.12 Time left:24d 20h 33m BH1750FVI Digital Light intensity Sensor Module For AVR Arduino 3V-5V power $2.18 Time left:21d 2h 16m Micro SD Storage Board Mciro SD TF Card Memory Shield Module SPI For Arduino $1.93 Time left:13d 2h 57m New Soil Hygrometer Detection Module Soil Moisture Sensor For arduino Smart car $2.55 Time left:29d 3h 28m USB To RS232 TTL UART PL2303HX Auto Converter USB to COM Cable Adapter Module $1.61 Time left:5d 5h 12m Mini PFM Control DC-DC USB 0.9V-5V to 5V dc Boost Step-up Power Supply Module $0.99 Time left:1d 8h 27m New design 20A range Current Sensor Module ACS712 Module Arduino module ACS712T $2.08 Time left:24d 3h 42m TTP224 4- Channel Digital Touch Sensor Module Capacitive Touch Switch Button New $2.56 Time left:28d 1h 19m 4PCS,Arduino NRF24L01+ 2.4GHz Wireless Transceiver Module New $3.90 Time left:8d 10h 4m TOP 5A CC CV LED Drive Lithium charger Power Step-down Module W/ USB Voltmeter $6.65 Time left:14d 1h 51m LM2596 DC-DC Buck Converter Step-Down Power Module+LED Voltmeter output 1.25-37V $4.01 Time left:24d 3h 58m Interface Base Board Serial Transceiver Bluetooth Module HC-05 06 For Arduino $1.28 Time left:5d 0h 3m 8-Bit LED 8-Bit Digital Tube 8 KeyS TM1638 Display module for AVR Arduino ARM $4.96 Time left:27d 22h 16m Arduino NRF24L01+ 2.4GHz Antenna Wireless Transceiver Module For Microcontroll $1.04 Time left:24d 7h 30m 10PCS Sound Detection Sensor Module Sensor Intelligent Vehicle For Arduino car $13.68 Time left:14d 3h 42m mini DC-DC Converter Step Down buck Power Supply Module for Flight Control Car $1.97 Time left:19d 4h 3m 2PCS Ultrasonic Sensor Module HC-SR04 Distance Measuring Sensor for arduino SR04 $2.95 Time left:25d 5h 9m TCS230 TCS3200 Color Recognition Sensor Detector Module for MCU Arduino $3.85 Time left:2d 6h 3m 10PCS LM2596 DC-DC adjustable power step-down module $13.56 Time left:1d 9h 9m 2PCS SI4432 470MHz 1000m Wireless Module 433mhz Wireless Communication Module $5.98 Time left:12d 23h 31m 6Pin USB 2.0 to TTL UART Module Serial Converter CP2102 STC Replace Ft232 Module $2.08 Time left:15d 2h 7m Wireless Serial 6 Pin Bluetooth RF Transceiver Module HC-05 RS232 Master Slave $5.43 Time left:10d 1h 38m 5V Two 2 Channel Relay Module With optocoupler For PIC AVR DSP ARM Arduino $1.76 Time left:24d 1h 54m Replace BMP085 5Pin 3.3V 5V BMP180 Digital Barometric Pressure Sensor Module $2.04 Time left:24d 0h 30m 5PCS Sound Detection Sensor Module Sensor Intelligent Vehicle For Arduino car $7.20 Time left:14d 3h 43m LM2577 DC-DC Adjustable boost Step-up Power supply Converter Module $2.34 Time left:8h 39m FT232RL USB to Serial adapter module USB TO RS232 Max232 for Arduino download $3.45 Time left:27d 23h 18m New JoyStick Breakout Module Shield PS2 Joystick Game Controller For Arduino $2.09 Time left:1d 23h 50m Payment We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Shipping We only accept your Ebay Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 1 business day by Hong Kong Air Mail when your payment is clear. The arrival time is 5-20 business days to United States usually. We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We ensure dispatch the item within 1-2 business days. However, you bought the item from opposite side of the earth, so it needs a little longer time to deliver. Please place order only if you agree with the shipping time and all the terms below. Customs duty is obligation and liability of a citizen in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. For example, Laser Pointer is unacceptable in some countries. Therefore, please double check your local customs policy carefully before purchase. Or, we will NOT be responsible for any failure delivery related destination customs issue. Warranty and Guarantee All package need to wait 30 days,Please take care it.Less than 30 days,we can't take a refund. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item. Contact Us If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a Week, and we will reply you ASAP. If no response within 24 Hours, please check the spam of mail box or kindly re-send it to us. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact. If you haven’t received item in 30 days, please contact us and we will arrange refund. We sell Electronic Components including Capacitors, Resistors, LEDs, Transistors, Diodes, Relays, Rubber Feet, Voltage Regulators, IC's, Bridge Rectifiers, Op Amps, Potentiometers, Ferrites, Inductors, Fans, Teflon Tubing, and other hard to find parts. If you need ,could contact us. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	100%NEW
Type	Motion Detectors
Model	HC-SR501
About Us	Only best quaity product,please choose us.
MPN	IR Pyroelectric
