Adjustable Step-down Power Module Dc 6v-32v To 1.25-32v Lcd Display V/i

US $180

Shenzhen, China
Jun 17th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Power Module Wireless Modules Sensor DIY LED Board Development Board Function Modules Digital Voltmeter Description Description: 1. Input voltage: 6V-32V DC 2. Output voltage: 1.25-32V(the input must be greater than the output of 1.5V or more) 3. Output current: adjustable, 5A max 4. Output Power: Max 75W (recommended in 50W) 5. Working temperature: -20 to +70 degrees 6. Operating frequency: 180KHz 7. Conversion efficiency: up to 96% 8. Short circuit protection:Yes 9. Overtemperature protection:Yes 10. Input Reverse Polarity Protection: None 11. Size:65.6*40*25mm Function Set by SET button: 1. Didplay output voltage:F-0 2. Display input voltage:F-1 3. Displayed alternately input/output voltage:F-2 4. Display USB input voltage and open&close USB output:USB Application: 1. Normal step down module 1>. Adjust potentiometer "ADJ-V" to set output voltage; 2>. Short ouput "+" and "-" and adjust potentiometre "ADJ-I" to set output current; 3>. Connect load 2. Battery charger 1>. Make sure battery's float voltage and charging current(if lithium battery is 3.7V/2200mAh,so the float voltage is 4.2V and max charging current is 1C ,); 2>. Under no-load conditions and adjuset "ADJ-V" to set output voltage at float voltage; 3>. Short ouput "+" and "-" and adjust potentiometre "ADJ-I" to set output current at charging current; 4>. Connect battery. 3. Constant current LED driver module 1>. Make sure LED working current and voltage; 2>. Under no-load conditions and adjuset "ADJ-V" to set output voltage at LED working voltage; 3>. Short ouput "+" and "-" and adjust potentiometre "ADJ-I" to set output current at working current; 4>. Connect LED. Shippment Payment Return Policy Feedback About us We will arrange shipping for you within 24 Hours after payment cleared except the holidays. We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address you would like us to ship to. If not, please let us know before we sent you the package, or we will not be responsible for any loss. hope you could understand. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. We accept Paypal ONLY. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. * We believe our items are so outstanding. We are convinced you will be happy with your Purchase. * If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund to you after the returned item arrived at our warehouse. * Please include your eBay ID and item number with any email requests. * When you satisfied with our product and services please leave us positive feedback. * If you have got the package, please confirm "Delivery on time" For us. * If a problem occurs, contact us immediately with any email request. * Just contact us using the " Ask the seller a question" link on eBay. We mainly sell Modules, IC Acccesories, Home Gadgets, and outdoor products. Almost all products you need, You can get a best price once you send us the ebay message. For bulk order or wholesale, we promise to offer you a very competitive price! We welcome do more pleasant business with you. SKYPE: ada-yu2013 inkfrog terapeak inkFrog Analytics On Jun-16-16 at 09:40:54 PDT, seller added the following information:
