Advanced Energy Pinnacle Plus 3152442-100a, 10kw Pulsed Dc Power Supply

US $1,950.00

Colleyville, Texas, United States
Jan 30th

Open on mobile:
QR code

Advanced Energy Pinnacle Plus 10kW DC Power Supply Mdl: 3152442-100A http://www.advanced-energy.com/upload/File/DC/ENG-PNCLPLUS-210-05.pdf Output Power Maximum 10 kW Voltage Range 325 to 650 VDC; Maximum Current 30.8 ADC Input Power Connector Five-terminal, DIN compression terminal block; maximum wire size: #6 AWG Output Connector Two-terminal, multi-contact, pluggable connector with strain relief or UHF connector Frequency 5 to 350 kHz, variable Reverse Time 0.4 to 5 ?s, variable; optional 0.4 to 10 ?s range Duty Cycle Up to 45% reverse time, variable Reverse Voltage 10% of operating voltage (just prior to reversal) Ignition Capability 1500 VDC max, 1350 VDC typical Regulation Modes Power, voltage, or current Repeatability From run to run at constant set point: 0.1% from 10 to 100% of rated power Input Power AC Line Voltage 480 VAC Current 480 VAC: 15 A nominal per ? Regulatory Compliance CE, NRTL on certain models Ground Reference Negative, positive, or floating output up to 1500 VDC with respect to ground or terminal to terminal I/O Control Specifications Analog Interface Options • 37-pin isolated (to 500 VRMS), 0 to 10 VDC analog, 0/24 VDC digital • 37-pin, 0 to 10 VDC or 0 to 5 VDC isolated analog, 0/15 VDC digital • 37-pin, 0 to 10 VDC or 0 to 5 VDC non-isolated analog, 0/15 VDC digital Serial Communication Options RS-232, RS-422, RS-485 (selectable baud rates up to 57.6 k): AE Bus protocol; ASCII protocol (MDX and emulation) Profibus (selectable baud rates of 1.5 MB or 12 MB); AE Bus protocol DeviceNet® option available Accessory Remote, active monitor/control panel Physical Specifications Size (Including Connectors) 133 mm (H) x 483 mm (W) x 675 mm (D) 5.22" (H) x 19" (W) x 26.57" (D) Weight 30 kg (66 lb) Maximum Recommended Output Cable Length 10 m (32.8') RG393 or equivalent Cooling Medium Air Input Power Connector Five-terminal, DIN compression terminal block; maximum wire size: #6 AWG Output Connector Two-terminal, multi-contact, pluggable connector with strain relief or UHF connector Shipping and Handling Order will be shipped via FedEx Ground. Most orders will be shipped within 24 hours after payment has been confirmed (weekends and holidays excluded). All orders are processed during business hours, Monday thru Friday from 8:00am to 5:00pm PST. Seller is not responsible for shipping damage. Terms 14 day return policy, buyer pays return shipping Payment We accept Paypal. If no response has been made within 3 days of auction end, winner will receive a payment reminder. We reserve the right to re-list this auction if payment is not made within 10 days of the auction end. Happy Bidding

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Advanced Energy
MPN	3152442-100A
Model	Pinnacle Plus
