Advanced Energy Pmh-13/3000 Power Measurement Head/sensor 3kw 13.56 Mhz Gencal

US $1,249.99

Phoenix, Arizona, United States
Jan 29th

Open on mobile:
QR code

Advanced Energy PMH-13/3000 Power Measurement Head/Sensor 3kW 13.56 MHz GenCal Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Advanced Energy and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit was an off the shelf tool from Intel. We do not have anyway to test it and are selling it as-is, NON-DOA. The Unit's Serial Number Tag Reads: Model Number: 3152290-000C Serial Number: 117527 F/R: C Link to the Datasheet: Advanced Energy GenCal Series Power Measurement Systems Datasheet Description: Each PMH is an in-line, bi-directional sensor between the power supply and the plasma load (or impedance-matching network in 13.56 MHz applications). The PMHs provide forward and reflected power measurements to the CEP. Specifications: Power: Full-Rated Forward Power: 3000 W Maximum Forward Power: 3300 W Full-Rated Reflected Power: 600 W Maximum Reflected Power: 660 W Power Scaling: Forward Power: 300 W per volt Reflected Power: 60 W per volt Frequency: 13.56 MHz ±5 kHz Impedance Range: 3:1 VSWR referenced to 50 System Accuracy: ±1% or 0.5 W (whichever is greater) into a 50 load when used with the CEP (calibrated to AE's internal standard and recalibrated every 6 months, maximum) Size: 113 mm H x 96 mm W x 65 mm D (4.45" H x 3.78" W x 2.54" D) - excluding connectors Weight: 0.91 kg (2 lb) Connectors: Input (from RF Power Supply): type HN coaxial, female Output (Load): type HN coaxial, female CEP Port: 12-pin modular, male For More Pictures Please Click the Following: Picture 2 - Sensor, Front View Picture 3 - Sensor, Back View Picture 4 - Sensor, Right Side View Picture 5 - Sensor, Left Side View Picture 6 - Sensor, Top View Picture 7 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $15.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 01/17/13 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Oct-31-13 at 21:09:55 PDT, seller added the following information: Click Here. Double your traffic. Get Vendio Gallery - Now FREE!

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“This unit was an off the shelf tool from Intel. We do not have anyway to test it and are selling it as-is, NON-DOA.”
