Advantest R3463 Modulation Spectrum Analyzer W/ Opts 09 15 61 30 Day "warranty"

US $1400

Hayward, California, United States
Jun 2nd

Open on mobile:
QR code

ADVANTEST R3463 MODULATION SPECTRUM ANALYZER W/ OPTS 09 15 61.30 Day Warranty Included With Unit. Ok Cosmetic Condition. The Advantest R3463 spectrum analyzer is a wide band, very sensitive receiver. It works on the principle of "super-heterodyne receiver" to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the Advantest R3463. The CRT displays received signal strength (y-axis) against frequency ( x-axis). Some applications for Advantest R3463 Spectrum Analyzers include Site Monitoring: Verify that the frequency and signal strength of your transmitter is accurate. Interference: Before a system is installed you use a Advantest R3463 spectrum analyzer to verify that the frequencies (you plan to use) are not occupied or if the presence of a very strong signal will interfere with your new setup. Interference can be created by a number of different situations. Other tests that utilize the Advantest R3463 spectrum analyzer features include antenna isolation, co-channel interference, adjacent channel power, occupied bandwidth, intermodulation, microwave or satellite antenna alignment, and characterization of components. Feature: Minimum Frequency: 9kHz Maximum Frequency: 3GHz Resolution bandwidth: 300Hz Measurement For Digital Mobile Communications For PHS, PDC and NADC Standards(GSM/DCS1800/DCS1900/DECT/CDMA Measurement Optional) Dual Mode Analysis Spectrum Analyzer Mode Digital Transmission Tester Mode Built-In Digital Modulation Analysis Function Menu OperationAutomatically Set Standard Parameters,STD Mode and Measurement Function Keys Compact, Lightweight (17 kg), 6.5 Inch TFT Color LCD 2 Slots Memory Card DriveModulation Spectrum AnalyzerRecently, digital mobile communication systems have been the focus of much attention. The R3463 is new modulation spectrum analyzers for testing these new communication systems.In addition to the functions offered by conventional spectrum analyzers, the R3463 has functions for analyzing digital modulated signals such as modulation accuracyand transmission speed. The units have an easy-to-use 'one key solutions' design that anyone can use. There are independent keys Digital Mobile Radio 1 Button Measurement Performance Characteristics of the R3463 Form Factor Mainframe Input Impedance 50 Ohm Minimum Frequency 9 kHz Maximum Frequency 3 GHz Frequency Accuracy 0.00000000001 % Zero Span Yes Minimum Span 2 kHz Maximum Span 3 GHz Minimum Sweep Time 50 ms Maximum Sweep Time 1000 s Minimum Resolution Bandwidth 300 Hz Maximum Resolution Bandwidth 3 MHz Resolution Bandwidth Steps 1/3/10 Minimum Video Bandwidth 1 Hz Maximum Video Bandwidth 3 MHz Video Bandwidth Steps 1/3/10 Maximum Safe AC Input 1 dBm Minimum Displayed Average Noise -115 dBm Maximum Displayed Average Noise -70 dBm Maximum Dynamic Range 1 dB Maximum Amplitude Uncertainty 15 % Trigger Source Internal Trigger Modes Freerun,TTL Demodulation AM,FM Connector type (main signal) Type-N(f) Cal Output Connector Type BNC(f) Probe Power No Noise Source Driver No Programmability/Connectivity of the R3463 User Interface Proprietary Data Storage Type PCMCIA R3463 Compliance CE Compliance Compliant UL Compliance Compliant R3463 Power Requirements Input Power Universal (Auto Sense and Switch) R3463 Physical Dimensions Width: (N/A) Height: 6.97 in(.27 in) Length: 16.54 in(.65 in) Weight: 37.48 lbs(82.62 lb) About us: Test Equipment Sales, Leasing & Acquisition Inc. D.b.a. TESLA Inc. Founded in 1991, TESLA incorporated in California in 1993. We BUY, SELL and REPAIR general purpose test equipment (GPTE). Located in Hayward CA. our facility is 8700 square feet with a 1000 sqft. Laboratory. We have about 4000 items in stock and in addition to GPTE there are chambers, RF amplifiers, EMC/EMI units and emulators. DON’T SEE WHAT you are looking for? Please call or Email Ken at 510-315-2459 or kenh@44tesla com. We buy and sell equipment world wide. MOTTO: "Integrity in Business"
