Aemc 2620 Leakage Current Probe (aemc Catalog Number 2125.52) New In Box

US $395.00

Alameda, California, United States
Jan 29th

Open on mobile:
QR code

AEMC 2620 ultra-sensitive leakage current probe- brand new in box never used. Retails for $549 + ship + tax new. Feel free to write with any questions. Leakage Current Probe Model 2620 (4A-1V/A, 400A-1mV/A output) Model 2620 The AC Leakage Current Probe Model 2620 measures leakage current shunted to ground caused by insulation faults. It enables the operator to locate failures when they occur, or anticipate them before they occur, without shutting down equipment or spending hours troubleshooting. It is designed specifically for locating low current faults on high current loads. The detector is a sensitive nickel alloy AC current transformer capable of measuring differential or leakage current as low as 500?A. It may also be used to measure current up to 400A continuous duty. Its 4” jaw opening facilitate both multiple and large conductors. The Model 2620 may also be used as a highly accurate clamp-on current probe, providing a versatile way to analyze unbalanced current measurements, leakage values on grounding conductors and ground loop currents. The Model 2620 has switch selectable ranges and is terminate with safety shrouded banana plugs on 5 ft leads, making it compatible with most multimeters. Applications: Preventive maintenance Equipment troubleshooting on electrical distribution systems High accuracy low-current measurements Measure fault currents on three-phase, three-wire systems ELECTRICAL - 4A Range Current Range 500?A to 4A Output Signal 1mV/mA (4V max) Accuracy 500?A to 10mA - 3% of Reading ± 1mV 10mA to 100mA - 0.5% of Reading ± 0.5mV 100mA to 4A - 0.5% of Reading ± 0.5mV Phase Shift 10mA to 100mA - <15° 100mA to 4A - <10° Load Impedance (DMM) 1M? min Frequency Range 48 to 1000Hz Output Termination 5 ft (1.5m) Lead with 4mm safety banana plugs MECHANICAL Dimensions 11.22 x 6.89 x 1.77" (285 x 175 x 45mm) Jaw Opening 4.4" (112mm) Maximum Conductor Size 4.4" (112mm) Weight 2.87 lbs (1300g) ENVIRONMENTAL Operating Temperature -14° to 131°F (-10° to 55°C); 0 to 85% RH (non-condensing) Storage Temperature -40° to 158°F (-40° to 70°C); 0 to 85% RH (non-condensing) SAFETY Safety Rating EN 61010-2-032, 600V Cat. III Double Insulation Yes CE Mark Yes

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	2125.52
Brand	AEMC
