Aflex-6300 Graphic Power Quality Analyzer/power Analyzer

US $3162

Shenzhen, China
Jan 29th

Open on mobile:
QR code

AFLEX-6300 Graphic Power Quality Analyzer/Power Analyzer Display of Overlapped Voltage and Current Waveform Maximum Demand (MD in W, KW, MW) with Programmable Period Harmonics Analysis ( V and I ) to the 50th Order Display of 25 Harmonics in One Screen with Waveform Display of waveform with Peak Values (512 Samples / Period), Datalogging of 32, 64, 128 or 256 Points/Cycles Analysis of Total Harmonics Distortion ( % THD-F ) Graphic Phasor Diagram Programmable PT (1 to 3000) Ratios Capture 128 Transient Events ( Time + Cycles + Faults ) with Programmable Threshold(%), Can Also be Reviewed in LCD 50000 Records with Programmable Interval ( 1 to 6000 seconds) Output of Waveform, Power Parameters and 50 Harmonics at Command. Large Dot Matrix LCD Display with Backlight Optical Isolated RS-232C Interface Smart Datalogging to save Battery Power for Long-term Monitoring Built - in Calendar Clock for Data Logging AC Watt ( 45 ~ 65 Hz, PF 0.5 to 1, CT=1 ) Range Resolution Accuracy of Readings 100.0 - 999.9 W 0.1 W 2% ± 8 dgts 1.000 - 9.999 KW 0.001 KW 2% ± 8 dgts 10.00 - 99.99 KW 0.01 KW 2% ± 8 dgts 100.0 - 999.9 KW 0.1 KW 2% ± 8 dgts 1000 - 9999KW 1 KW 2% ± 8 dgts AC Current (45~65 Hz , True RMS) Range Range Resolution Accuracy of Readings 30 - 300 A 0.00 - 300 A 0.1 A 1 % of range ± 8 dgts 300 - 999.9 A 100.0 - 999.9 A 0.1 A 1 % of range ± 8 dgts 1000 - 3000 A 1000 - 3000 A 1 A 1 % of range ± 8 dgts Harmonics of ACA in % and Magnitude (1 to 50th order) Range Resolution Accuracy in % Resolution Accuracy in Magnitude 10.0 - 300 A 0.1 % ±1.0% 0.1 A ±1.0% of range ± 0.8A 1000 - 3000 A 0.1 % ±1.0% 1 A ±1.0% of range ± 3 A Power Factor (PF) Range Resolution Accuracy of Readings 0.00 - 1.00 0.01 ± 1.5 % ± 8 digits Harmonics of AC Voltage in % and Magnitude (1 to 50th order) Range Resolution Accuracy in % Resolution Accuracy in Magnitude 50 - 600 V 0.1 % ±0.5% 0.1V ±0.5 % ± 0.5V General Specification: Conductor Size 150 mm (approx.) Battery Type 1.5 V SUM-3 *2 Display 128*64 Dot Matrix Power Consumption 10 mA (approx.) Auto - Power - Off 15 minutes LCD update rate 2 times/sec Dimension 130mm(L)*80mm(W)*43mm(H), 5.1"(L)*3.1"(W)*1.7"(H) Accessories Test lead*1 pair, Users manual*1, Batteries 1.5V*2 No. of Sample / Period 512 ( V & A ), 256 (W) Operating Temperature -10 to 50 Operating Humidity < 85% RH Storage Temperature -20 to 60 Storage Humidity < 75 % RH Weight 450g Edited by Johnny PAYMENT INFORMATION: 1.We can accept Credit Cards,Paypal,T/T,Escrow and so on. 2.The buyer is responsible for any tax and/or duty charged by their country. INTERNATIONAL SHIPPING: The package will be shipped by DHL, FEDEX or EMS. After we shipped the parcel,we'll fill in the tracking number and inform you by e-mail.Please write the correct address and telephone number when you make orders,so the courier can contact you when they deliver the parcel to you. thanks WARRANTY INFORMATION: 1.All the products have been checked and packed in good condition before dispatch. 2.All the products with one year warranty. 3.If you find any quality problems,please send it back within 3 days,and we'll send you a new one or refund you the payment after we get the returned one. 4.Buyers have to pay for the return cost and we will pay the cost for resend 5.All products returned should be in new conditions. CONTACT US: Office Tel: 008675527541660 Cellphone: 008615967476828 1.A good feedback is very important for our store,if you feel satisfied with our products,please give us positive feedbacks. 2.Please contact us before leaving any negative or neutral feedback,We will work with you to solve any problems

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TES
Country/Region of Manufacture	China
Model	AFLEX-6300
