Agie Model Ac Classic 2, New In 2001

US $69,500.00

Ames, Iowa, United States
Jan 30th

Open on mobile:
QR code

AGIE MODEL AC CLASSIC 2, NEW IN 2001 SPECIFICATIONS EQUIPMENT DIMENSIONS ---------------- 1640 X 2040 X 2220 MM WEIGHT OF EQUIPMENT ----------------- 2,680 KG UTILITIES: RATED LINE POWER -------------------- 9,7 KW LINE VOLTAGE ------------------------ 3 X 400 V ± 10% MAX. WORKPIECE DIMENSIONS ----------- 750 X 550 X 250 MM (2S: WITH BATH, H MAX. = 150MM) MAX. WORKPIECE WEIGHT --------------- WITH BATH 200 KG TRAVELS: X AXES --------------------- 350 MM Y AXES --------------------- 250 MM Z AXES --------------------- 256 MM U/V AXES ---------------------------- ± 70/ ± 70MM MAX. TAPER <° / HEIGHT -------------- 30° / 100 MM HIGH SPEED MOTION: X,Y AXES --------- 900 MM/MIN U/V/Z AXES ------- 600 MM/MIN DRIVES: X/Y/U/V/Z AXES -------------- BRUSHLESS AC SERVOMOTORS AGIEJET WIRE THREADING SYSTEM: THREADABLE HEIGHT ---------------- UP TO 250 MM THREADING NOZZLES----------------- 2/MM / 1MM OPTION COMBINATION WIRE GUIDE SYSTEMS: WIRE DIAMETER -------------------- 0.2 ? 0.33 MM GUIDE ------------------------ CYLINDRICAL TO 2° TOROIDE GUIDE -------------------- 2° ? 30° WIRE DRIVE: WIRE SPOOL ----------------------- UP TO 25 KG WIRE TENSION --------------------- 0 ? 25 N WIRE SPEED ----------------------- 60 ? 300 MM/S WIRE FEED ------------------------ SEMI-AUTOMATIC WIRE DISPOSAL -------------------- CHOPPER WORK TANK: DOOR ----------------------------- MANUAL DROP TYPE ACCESSIBILITY -------------------- FRONT CLAMPING BASE -------------------- LEFT/RIGHT BEAM WITH SUPPORTING PLATE OPERATING MODES ------------------ AGIEDUOFLUX FLUSHING: PRESSURE ------------------------ 0.2 ? 18 BAR PROGRAMMABLE COMBINATION --------------------- COAXIAL FLUSHING/ HIGH & LOW PRESSURE/ SUCTION FILTER (2S) ------------------------ 4 CASINGS WITH 8 CARTRIDGE FILTERS CONTROL ---------------------------- AGIECUT/AGIEVISION EQUIPPED WITH - REMCOR CHILLER S/N 636-835-134 - CAMTEK MECANIC- UNIVERSAL TABLE - AGIE JOGGER - VOLTAGE 480
