Agilent 5DX Series 3 Automated X-Ray Inspection ; Very Fine Pitch ; Model 5300 Powered by SellerVantage Product DescriptionPaymentShippingReturnsAbout UsLegal Agilent 5DX Series 3 Automated X-Ray Inspection ; Very Fine Pitch Model 5300,5DX,Series,3 Manufacture date: 11/27/2000 Serial # US40690604 The Agilent 5DX Series 3 is designed for In-line Automated Process Testing of solder connections on PCB assemblies, with pass-thru or pass-back loading. The system can be used for all standard joint-types and fully supports inspection of single and double-sided boards having dimensions up to 457 x 609 mm (18 x 24 inch). Digital cross-sectional X-ray images of solder joints are automatically generated and analyzed. The analysis results includes a complete quantitative description of each joint, as well as a lit of all defective solder connections found. Special confirmation and adjustment routines provide solder thickness of key solder joint parameters. Solder thickness from 0.05 to 0.25 mm (0.002 to 0.010 in.) can be measured with a repeatability standard deviation of less than 4% for all component types except capacitors and through-hole. Note: the minimum repeatability standard deviation is 0.0025mm (0.0001 in.) The exact speed depends on the density of the component layout on the circuit board. Generally speaking, the more dense the circuit board, the higher the test speed. The typical range in test speeds is from 80 to 140 joints/second (including inspection, alignment, surface map, and board handling time). Image Acquistion Time (including movement): Up to 5 images per second Load/ Unload Time: 12 seconds per panel for pass-through mode, 15 seconds for pass-back moade, 6 seconds per panel using dual loading Alignment Time: 3 to 8 seconds (depending on board size) Surface Map Time (Points/Second): Up to 5 points/sec (typical map density is 1 point / 645-2580 sq.mm (1-4 sq. inches) Total system weight with machine and electronics rack: 3400 kg (7500 lbs.) http://www.keysight.com/upload/cmc_upload/All/59688840e.pdf?&cc=US&lc=eng Payment Pay with your credit card through PayPal. All in state residents within our state will be charged state and/or local sales tax at the time of checkout. Payment must be received within 7 days of the close of auction. If payment isn't received within 7 days, the auction will be revoked and a Non-Paying Bidder alert will be filed. Shipping Packages are usually shipped within 48 hours of payment receipt (excluding Saturday/Sunday) Shipping costs for all orders can be determined by the shipping calculator in this auction. All orders are shipped via UPS, FedEx, DHL, or USPS. International buyers, please be aware that you may incur a brokerage and/or customs fee upon delivery. Winning bidder is responsible for shipping charges. We reserve the right to choose carrier based on shipping method selected at time of payment. Combined shipping is done at the sellers discretion. If you purchase more than one item from us, they may arrive in separate packages. PFI of Florida: 607 Savage ct longwood, FL 32750 Telephone: 4078224499 Returns All items are sold as-is. We accept returns only if the item was not as described in the auction. Buyer must return the item exactly as received within 7 days and will be responsible for all additional shipping charges. We do our best to present accurate, detailed information about every item we sell. If you have any questions, please contact us before placing your bid. About Us PFI is a Florida Corporation who has been doing business since 1981 we are available 5 days a week from 8-4 our main phone number is 407-822-4499 Legal PFI of Florida has used its best efforts to inspect the item(s) for sale and create descriptions and furnish photographs that fairly and adequately depict the type, condition and image of the goods at the time of sale. PFI of Florida makes no express or implied warranties or representations regarding the condition or suitability of the goods and to the extent allowed by law, specifically disclaims any express or implied warranties, including but not limited to any warranty of merchantability or fitness for purpose. Any warranty expressed in the listing itself superceeds these terms. PFI of Florida reserves the right to cancel bids on any item due to feedback. Seller Name: pcbassyequip Add to Saved Sellers Powered By SellerVantage, an Inventory and Consignment Software Solution

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Agilent
MPN	5300
Model	5DX Series 3
Country/Region of Manufacture	United States
