Agilent 6811b Ac Power Source/power Analyzer, 375va, 300v, 3.25a, Tested Good

US $1800

Terrell, Texas, United States
Jun 2nd

Open on mobile:
QR code

This is an Agilent 6811B AC Power Source/Analyzer. The Agilent 6811B is ideal for applications such as power supply testing, UPS testing, avionics ATE, the testing of power factor corrected equipment and devices. Set up is made easy with the Graphical User Interface, which requires no programming. The Agilent 6811B provides a complete AC and DC power and measurement solution with extensive features to protect valuable DUTs. Save space on a lab bench or in a test rack with this flexible instrument. With the built-in power analyzer, this AC Power Source / Power Analyzer combines the capabilities of a multimeter, oscilloscope, harmonic analyzer, arbritrary waveform generator, and power analyzer all in one device. This instrument may also be used to produce DC power, either alone or as a DC offset to an AC waveform. An optional second power analyzer is available, which can be used independently from the source, or for dual-node measurements such as power supply input/output efficiency tests. Output Ratings Power: 375 VA Voltage rms: 300 V Current rms: 3.25 A Repetitive & non-repetitive peak current: 40 A Output Frequency Range DC; 45 Hz to 1 kHz Ripple & Noise (20 kHz to 10 MHz) -60 dB (relative to full scale) Line & Load Regulation Line regulation (% of full scale): 0.1% Load regulation (% of full scale): 0.5% Measurement Accuracy Rms. Voltage (35 - 100 Hz): 0.03% + 100mV DC Voltage: 0.05% + 150 mV Rms. Current (45 - 100 Hz) o High Range: 0.05% + 10mA o Low Range: 0.05% + 1.5mA Power (VA) (45 - 100 Hz) o High Range: 0.1% + 1.5VA + 12 mVA/V o Low Range: 0.1% + 1.5VA + 1.2 mVA/V. This unit has been fully checked in our lab and is guaranteed completely operational. High bidder to pay $75 S&H if within the USA. International bidders please contact me for shipping quote. TERMS AND CONDITIONS: Texas residents must pay sales tax unless a tax exemption/resale certificate is provided. All of our items are packed with Insta-Pak foam in place packing. We ship FedEx or UPS Ground in the continental USA. We ship FedEx or UPS International for our international customers. USPS Shipping is available ONLY via services that provide a tracking number (Priority, Express, etc)! We have had too many misplaced/lost/missing packages shipping with the US Postal Service. If you would like to have your item shipped on your own shipping account, please let us know, and we will take off the shipping cost. Please only bid on our items if you have the intention of paying for it. Please contact us if you have any questions regarding our Ebay listings. We describe everything to the best of our ability. Our lab has capabilities from DC up to 50/67Ghz, and all items we sell are tested before listing on Ebay. If an item has a known problem, or if we cannot test it to the fullest extent, we will be up front and will list that in our description. All items we sell come with a 30-day warranty, unless otherwise listed in the description. NOTHING is included that you do not see in the picture. There are no feet, no handles, no rack mount ears, no accessories, no probes, no cables, no manuals, and no certificates of calibration included unless specifically stated in the description on our auctions. Any cables shown in the picture are strictly to demonstrate the operability of the item in the auction and are not included. We DO NOT check the operation of the HPIB buss on items priced under $1000 due to the amount of time it takes. If you would like to purchase accessories such as feet, handles, rack mount ears, cables, etc., please contact us at the end of the auction or before it closes and we can give you a price on them.
