Agilent 85025b 10mhz-26.5ghz 3.5mm Detector

US $1,199.00

  • Ichihara, Chiba , Japan
  • Jan 29th
        Agilent 85025B 10MHz-26.5GHz 3.5mm Detector        10MHz-26.5GHz 3.5mm(m) 50ohms Max20dBm(100mW) 10VDC DynamicRange -55-+16dBm(ACmode) -50-+16dBm(DCmode) ReturnLoss 10-40MHz 10dB 40M-4GHz 20dB 4G-18GHz 17dB 18-26.5GHz 12dB Responce +0.25dB-0.75dB(10-40MHz) +-0.5dB(40M-26.5GHz) Acc0.4dB 0.24Kg Cable 2m Maker Price : JPY2,070,000- The Agilent 85025B detector is designed specifically for operation with the Agilent 8757D scalar network analyzer and is not compatible with the 8756 or the 8755. The 85025B detects either a modulated (ac) or an unmodulated (dc) microwave signal.  Warranty: Acceptance Test 5days return right   Web shop : www.hitechfacility.co.jp
