Agilent 86100c Infiniium Dca-j Oscilloscope Mainframe 092,701 Nist Calibrated

US $11,500.00

Oceanside, California, United States
Aug 5th

Open on mobile:
QR code

This Agilent 86100C with options 701 (Standard Trigger Bandwidth 2.5Ghz) is in excellent condition. No modules are included in the sale. Mainframe Only! The 86100C DCA-J combines extremely high accuracy and precise repeatibility with great ease of use to simplify characterizing signals from 50 MHz to 80 GHz. Features and Benefits: User configurable: mainframe with slots for two modules (4 optical or electrical channels) Trigger bandwidth up to > 13 GHz (option 001) Clock recovery with adjustable loop bandwidth Integration with MATLAB signal filtering and measurement automation software available The most comprehensive multi-function analyzer for high speed electrical and optical signals The 86100C DCA-J combines extremely high accuracy and precise repeatability with great ease of use to simplify characterizing signals from 50 MHz to 80GHz. Digital designers can combine the mainframe and modules into four key instruments with industry leading signal integrity performance, including: A digital communications analyzer with automated eye diagram analysis for transmitter compliance testing A full-function time domain reflectometer (TDR) for high precision S-parameter impedance analysis A full-function oscilloscope with bandwidth in excess of 80 GHz, ensuring the most accurate waveform measurements The industry's most accurate jitter analyzer, measuring subcomponent jitter sources with one-button ease of use

“No modules are included in the sale. Mainframe ONLY!”

Model

86100C

MPN

86100C

Configuration

001 100

Brand

Keysight Agilent
