Agilent Hp 58516a Gps L1 1:4 1575.42mhz 30vdc Distribution Amplifier W/ Cables

US $99.00

Santa Fe, New Mexico, United States
Mar 11th

Open on mobile:
QR code

This is untested lab surplus, but guaranteed not to be DOA. As you can see from the photos, it is in excellent condition, and comes with assorted cables and connectors. From HP: HP 58516A GPS L1 DISTRIBUTION AMPLIFIER Frequency Bandwidth (3 dB) 1575.42 MHz +/- 20 MHz Gain (antenna to output) 0 dB +/- 3 dB @ 1575.42 MHz Noise Figure <7.0 dB (5.0 dB typical) @ 1575.42 MHz VSWR <2.5:1 (1.5:1 typical) @ 1575.42 MHz Isolation > 40 dB @ 1574.42 MHz (L1) > 40 dB @ f=L1 + 40 MHz DC Power (Port 1) Operating Voltage Damage level Operating current Maximum input current Note: Ports 2 through 4 are terminated with a 200? resistor to simulate the load of a GPS antenna +4.5 Vdc to +30 Vdc >30 Vdc, either polarity 10 mA 450 mA AC Input Level (antenna signal) Impedance Maximum operating Damage level 50? nominal -25 dBm +13 dBm AC (output ports) Impedance 50? nominal Operating Environment 0°C to +55°C Operating Humidity 40% to 85%, non-condensing Dimensions (including connectors) 88.4 mm (3.5 in) W x 121 mm (4.76 in) L x 30.7 mm (1.2 in) H Connectors Female N-type connectors Weight 0.5 kg 1. INTRODUCTION 1.1. The HP 58516A GPS L1 Distribution Amplifier is one component of a complete line of GPS accessories for your GPS antenna system available from Hewlett-Packard. These accessories are designed to deliver precise GPS signals over a wide temperature range and in harsh environmental conditions. 1.2. The distribution amplifier is required if you wish to distribute the signal from a single antenna to as many as four GPS receivers. 2. DESCRIPTION 2.1. The HP 58516A consists of a broadband, unity gain amplifier and a 1:4 signal splitter. Designed for use with GPS antennas, the unit features a high degree of isolation to eliminate feedback and interaction between any GPS systems connected to it. 2.2. Power to the splitter is supplied by the GPS timing receiver connected to Port 1. 3. USE WITH HP AND NON-HP SYSTEMS 3.1. Although designed for use with HP GPS frequency and time receivers, the HP 58516A can be used with other GPS receiver and antenna systems. 3.2. The HP 58516A operates over a voltage range of +4.5 Vdc to +30 Vdc. Voltage is supplied via the connecting cable (the center conductor is positive with respect to the shield) to Port 1 of a standard unit, or through an external dc power input on a unit with Option 05Q. Caution: Power to the HP 58516A will be passed to the rest of the antenna system. For example, if a +30 Vdc supply is used to power the HP 58516A, the +30 Vdc will be passed through to the antenna. When using the HP 58516A with an HP 58504A GPS antenna, the maximum voltage should be no greater than +5.5 Vdc. Thanks for looking at my items. I am splitting my time between two cities. I try to schedule auctions to end when I am where the item is. Buy It Now items will ship within two days, if I am where the item is, otherwise, it could take up to 10 days for me to ship it to you. If this will be a problem, please contact me before buying, and I will tell you how soon it can be shipped.

“This is lab surplus, in excellent condition! Look at the photos.”

Brand	Agilent / HP
MPN	58516A
