Agilent / Hp 81104a Pulse-/pattern Generator W/ 2x 81105a

US $2,160.00

Fremont, California, United States
Jan 29th

Open on mobile:
QR code

Agilent / HP 81104A Pulse-/Pattern Generator * w/ 2x 81105A Output Module *Please read & carefully review Network_37’s “Product / Purchase Details” (below) and reference listing pictures* Key Features & Specifications Single-/dual-channel pulse pattern generator 80 MHz, 10 V from 50 Ohm into 50 Ohm Triggerable / PLL operation selectable Pulse / burst / pattern modes selectable Variable transition times BNC outputs, single-ended Single- or dual-channel: Requires 1 or 2 output modules 81105A Description The Agilent 81104A 80 MHz Pulse Pattern Generator with one or two Agilent 81105A output modules (single-/dual-channel) builds on the performance of the 81101A and is backward-compatible. The 81104A extends the frequency range and adds RZ/NRZ pattern capability up to 16 kbit per channel. An NRZ strobe channel provides a trigger at arbitrary points in the pattern, or can be used as an additional pattern source. If two 81105A Output modules are available, the outputs can be added. This allows elaborate pulse shapes for simulating glitches, testing clock-recovery circuits or generating 3- or 4-level codes. Channel-add and 1000 Ohm source modes each operate up to about 60 MHz. Combined, the maximum speed is about 15 MHz. Network_37 Product / Purchase Details: This listing is for a quantity of one used Agilent / HP 81104A Pulse Pattern Generator with a quantity of two 81105A output modules. No accessories are included in this listing. The generator is in good physical condition with normal wear & tear. There are no major dents or cosmetic defects. The unit pictured is the actual unit being auctioned. The unit passed basic self-test upon start up. No further testing has been done. Shipping cost varies by buyer's location. This unit ships only within the continental United States. This generator will be carefully hand packed using quality boxes & packing/protection materials. 14-day form & function warranty as described in this listing.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Agilent / HP
MPN	81104A
Model	81104A
