Agilent Hp 83712a Synthesized Cw Generator

US $6,499.99

  • San Diego, California, United States
  • Mar 28th
Open on mobile:
QR code
Up for sale is Agilent HP 83712A SYNTHESIZED CW GENERATOR. Condition is USED, may show signs of sticker residue or wear. Top of Form Bottom of Form The HP 83712A synthesized CW generator has a carrier frequency range of 10 MHz to 20 GHz. Frequency Range: 0.01 to 20.0 GHz Resolution: 1 kHz, 1 Hz with option Aging rate: <1.0 x 10-8/day after 72 hours, <1.5 x 10-9/day after 24 hour warmup - with option Frequency switching time: <50 ms to within 1 kHz RF output Maximum leveled output power: +13 dBm at 0.01 - 1 GHz, +11 dBm at 1-20 GHz (+10 dBm with option) Minimum leveled output power: 0 dBm, -90 dBm with option Display resolution: 0.01 dB Flatness: ±0.5 dB for power >=-90 dBm, ±0.7 dB for power <-90 dBm (The use of Type-N RF connectors above 18.0 GHz degrades specification typically by 0.2 dB) Level switching time: <17 ms (without step attenuator range change) Output SWR: <2.0:1 nominal Harmonics: <-55 dBc at output levels <+6 dBm, 0.01 to 1 GHz; <-50 dBc at output levels <+6 dBm, 1 to 20 GHz Non-harmonic spurious: <-60 dBc (>=3 kHz), <-50 dBc (<3 kHz) Residual FM: At 1 GHz, <15 Hz in 50 Hz to 15 kHz bandwidth. Residual FM decreases 6 dB per octave below 1 GHz AM noise floor: (at 0 dBm and offsets greater than 5 MHz from carrier) <-150 dBm/Hz, 1-20 GHz; <-140 dBm/Hz, 0.01-1 GHz Front panel connectors RF Output: The standard front panel RF Output connector is a Type-N precision connector. When Option 1E9 is installed, this front panel connector is a 3.5 mm precision connector. The nominal source impedance is 50 ? ALC In: This front panel BNC connector allows the synthesizer to be externally leveled. It is used with external power meter leveling or external diode leveling. The leveling signal at this input must be in the ±1 V range. The nominal input impedance is 150 ?. The damage level is >=+12 V or
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Keysight Agilent HP
MPN 83712A
Model 83712A
