Agilent / Hp 8720d Network Analyzer: 50 Mhz To 20 Ghz W/ Option 010, 012 & 400

US $15,195.00

Oceanside, California, United States
Jan 29th

Open on mobile:
QR code

AGILENT 8720D NETWORK ANALYZER *Call (760) 806-6600 to RENT this item* DESCRIPTION The HP Agilent 8720D Network Analyzer features a frequency range of 50 MHz to 20 GHz, a drastically faster processor compared to earlier versions, a built-in fast sweeping synthesized source, an integrated solid-state switching S-Parameter Test Set, Vector Receiver, Error Correction and the tuned receivers provide up to 105 dB dynamic range. The HP 8720D allows fast tests of microwave linear and nonlinear devices in both coaxial and non coaxial environments, such as waveguide, in-fixture, and on-wafer. With a relatively small foot-print compared to earlier network analyzers, the 8720D is perfect for cost-conscious engineers, short on bench space. It is perfect for R&D, manufacturing, or quality assurance. The "Fast" processor is seven times faster than earlier versions of the 8720 series. The fully synthesized source (in both swept or stepped modes) offers stability and accuracy within 10 ppm (typical). Frequency resolution is 1 Hz standard for accurate measurements of narrow band or long-delay devices. Two independent channels can measure and display all four S-Parameters simultaneously. Reflection and transmission measurements can be displayed in a variety of formats, including magnitude, phase, group delay, SWR, and Smith Charts. # Built-in vector accuracy enhancement provides excellent error corrected accuracy in common coaxial connectors, A user kit supports user-defined standards, and allows calibration in waveguide. Adapter removal calibration provides greater accuracy for measurements of non-insertable devices, such as devices with same sex connectors on both ports or different connector types on ports 1 and 2. The HP 8720D offers powerful features for active devices. With +5 dBm at the test ports, it has plenty of power for testing amplifiers. For sensitive small signal devices, the built-in step attenuator can cut power back to -70 dBm. Absolute power levels can be set accurately anywhere in the system, using the power meter calibration function. Power sweep capability and power resolution of 0.01 dB make it easy to test the gain-compression characteristics of active components. A sweep mode controls power during retrace for safe testing of AGC amplifiers. For On-Wafer device characterization, use the TRL/LRM calibration to minimize fixture errors for measuring noncoaxial devices, such as microstrip. # Productivity enhancements of the 8720D include a swept-list mode that reduces measurement time by allowing you to choose the frequencies you want to test, and to set independent IF bandwidths and power levels in each frequency range. Fast two-port tuning mode speeds up 12-term error correction by allowing the user to specify the number of forward sweeps to take before updating the reverse sweep. Users can automate repeated measurements with test sequencing. You can create test sequences with a single keystroke. And additional features include limit testing for consistent pass/fail results, up to 5 markers per channel, serial and parallel interfaces for connecting to printers, a VGA compatible output for adding a larger external monitor, 2 MB of internal non-volatile memory for storing up to 31 test configs. Notes / Included Options: 010 - Time Domain Capability 012 - Direct Sampler Access 400 - Adds fourth sampler and TRL *All of our equipment has been tested. Additional Calibration may be available upon request! ~Item sold with shown accessories, a power cord and manual on CD (when available)~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback And although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. All orders also come with a limited 5-day ROR (Right of Return). This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or an item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer, equipment that has been misused or damaged by customer's misuse (intentional or unintentional), or any orders damaged in transit. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your own shipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Equipment has been tested and is fully functional with a 30-day Warranty”
