Agilent Hp Esa-l1500a Model E4411a 9khz - 1.5 Ghz Spectrum Analyzer W Case

US $3,500.00

Broomfield, Colorado, United States
Jun 9th

Open on mobile:
QR code

Agilent HP ESA-L1500A model E4411A 9KHz - 1.5 GHz Spectrum Analyzer w Case. This looks and works good and comes with a 30 day Warranty! The Agilent/HP ESA-L1500A (E4411A) 1.5 GHz Portable Spectrum Analyzer has the performance of a high-quality spectrum analyzer and the rugged ease of use expected in a field instrument. The Agilent/HP ESA-L1500A gives you a rapid display update rate and state-of-the-art 5 ms sweep time that reduces test time and increases throughput. The phase-locked synthesizer adds stability and repeatability to frequency measurements, and the automatic background alignment offers continuous calibration. Plus, you'll have specified performance only 5 minutes after power-up. Features 4 ms RF sweep time Combined with 28 measurements per second, provides virtual real-time updates. Responsive display makes circuit adjustment easier, while increasing the probability of intercepting intermittent signals. High-speed data transfer (GPIB) Fast processing helps reduce measurement time in ATE environments. Fully synthesized design Provides continuously phase-locked precision throughout the entire sweep. Improves frequency accuracy, stability, and measurement repeatability, eliminating drift. Amplitude correction Calibrates out frequency-related amplitude effects with built-in amplitude correction. Automatic background alignment Continuously calibrates the analyzer. Guarantees repeatability over changing temperatures. 85 dB calibrated display range Allows simultaneous display of large and small signals. Increase your manufacturing up-time: costly repairs can be avoided with the automatic input overload protection, and the use of component integration reduces the probability of failure. Ideal for field environments, the Agilent/HP ESA-L1500A has a sealed front panel, louvered air vents, and side-mounted fan to protect the instrument in a wide range of weather conditions. Rubber-encased front and rear frames resist the rigors of transportation. The combination hard key/soft key front panel offers simple operation for basic measurements while providing access to sophisticated features. In addition, testing is simplified with built-in limit lines and pass/fail messages. The Agilent/HP E4411A (ESA-L1500A) Portable Spectrum Analyzer is economical, portable, has rugged packaging and construction, and is easy to use. The unit has a frequency range of 9kHz to 1.5GHz with frequency accuracy of ±2.0kHz at 1GHz (without temperature). Phase noise is <= -90 dBc/Hz (10kHz offset) and residual FM is <=100 Hz P-P. Other specifications include: Resolution bandwidths 1kHz to 3MHz Maximum amplitude range -120 dBm to +30 dBm Maximum dynamic range >=78 dB/>=85 dB (2nd/3rd order) Log range 85 dB with 10 divisions on screen; 15.8 cm, high resolution LCD display, continuous background environment alignment

“This looks and works good and comes with a 30 day Warranty.”

Brand	Agilent
MPN	E4411A
Model	ESA-L1500A
