Agilent J7211c Lx1 Attenuation Control Unit

US $1100

Moscow region, Russian Federation
Jun 23rd

Open on mobile:
QR code

Hi! Up for bidding is a very lightly used Agilent J7211C LX1 Attenuation Control Unit. Missing original box but looks like new. Was bought for the project and no longer needed. Calibration sheet included. Tested and found fully working. Priced to go! J7211C attenuation control units provide an integrated solution for R&D and manufacturing engineers in wireless communication, aerospace and defense and electronic component industries. Operating from DC to 26.5 GHz, the J7211C provides attenuation up to 101 dB with a 1 dB step size. A unique attenuation sweep function lets you select start/stop attenuation, step size, dwell time and number of cycles of for your application. J7211C offers exceptional < 0.03 dB insertion loss repeatability per section for the entire 5 million cycles which reduces your cost of ownership. Designed in a compact half-rack, 2 unit high form factor, the Keysight J7211C ensures ease-of-use in benchtop applications and greater efficiency and throughput in ATE testing. GPIB, USB and LAN connectivity (LXI Class C Compliant) allow easy remote control and triggering. Attenuation sweep function – define the sweep time, number of cycles and step size for your application Relative attenuation step function - set attenuation relative to any value Attenuation steps - 0 dB to 101 dB, 101 dB to 0 dB, or back and forth for the preset number of cycles (1 to 1000) User selectable sweep time - 50 ms to 10 s; 50 ms incremental The winning bidder receives exactly what is pictured, no other accessories. WYSIWYG. Item is in Moscow region, Russia. Shipping with EMS (Express) Russian post worldwide. Will pack securely. ETA to the USA is approximately 2 weeks. The device is guaranteed not to be DOA but no returns due to dishonest people swapping parts. Bid with confidence. Good luck and happy bidding! Thanks for looking!
