Agilent U2001a 10 Mhz - 6 Ghz Usb Power Sensor (opt. 100) Tested!!! Bundle 2x

US $1,495.00

Boise, Idaho, United States
Mar 10th

Open on mobile:
QR code

You are bidding on ONE bundle of TWO U2001A USB Power Sensors Used but in EXCELLENT WORKING condition w/ TWO original Agilent USB Cables. GUARANTEED WITH TEST RESULTS. Signal Generator HP 8648B is NOT included! The Agilent U2001A is a standalone RF Power Sensor that operates like a power meter. It's fast measurement speed helps reduce test time. This, coupled with the capability to enable monitoring of more than 20 channels simultaneously, is an advantage in the production line where efficiency is of utmost priority. The U2001A has both internal and external zeroing capabilities. With internal zeroing, high isolation switches in the sensor are opened to isolate the sensor from the device-under- test (DUT) it is connected to. The U2001A USB power sensor is a true-average, wide-dynamic-range RF/microwave power sensors, based on a dual-sensor diode pair/ attenuator/diode pair topology. Specifications. Frequency range: 10 MHz to 6 GHz. Power range: -60 to +20 dBm. Maximum power: +25 dBm avg 20 VDC, +33 dBm pk < 10 µs. Maximum SWR: 1.15 (10 to 30 MHz), 1.13 (30 MHz to 2 GHz), 1.19 (2 to 6 GHz). Measurement speed Normal: 20 readings/s. Measurement speed Fast: 110 readings/s. Average only mode (default mode): optimized for wide dynamic range. In this measurement mode, a trigger can be controlled externally via TTL input. Normal^2 mode: used for making average power measurement in a defined time interval (time-gated measurement) with reduced dynamic range. A trigger can be derived from an RF signal (internal trigger) or controlled externally via TTL input (external trigger). Accuracy (25 °C ± 10 °C): ±3.0% (60 to +20 dBm). Current requirement: 200 mA max (approximately). Connector type: N-type male, 50 ohm.

Condition

Used :

An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.

Seller Notes

“In Excellent Working condition see photos. (The SN. MY51200016 in the photo is used for reference only to illustrate the test configuration and I will / can provide such test verification for each U2001A sold [the units ALL test with nearly identical results] )Signal Generator NOT included!HP 8648B Signal Generator displayed to DEMONSTRATE that this item is in working condition and is NOT included with this sale.”
