Air-compressor In-tank Check Valve 3/4 Mpt X 3/4fmpt

US $286

Hartford, Wisconsin, United States
Jun 12th

Open on mobile:
QR code

SquareTrade © AP6.0 Control Devices Corporation Part# FF6X209 Economical, reliable brass in-tank check valves for compressors, air tanks. Fluoropolymer poppet, stainless steel springs. Check valves have been tested to 400 Degrees F. for Air; rated 400 PSI Max. pressure. External threads are coated with Loctite Vibra-Seal 516 dry type thread sealant. Inlet or Air Line from compressor fitting: 3/4" Female Pipe Thread Outlet or tank side fitting: 3/4" NPT Male Pipe Thread The bottoms threads of this valve are: 3/4" Male Pipe thread, this is the side that screw into the air tank. The top of this valve where the discharge tube or line that comes off the compressor connects to is 3/4 FEMALE PIPE THREAD. The threads for the bleed line is 1/8" Female "NPT" thread and comes with a plug which can be left in or removed to connect to the bleeder line or unloader line. For Industrial and Commercial applications. INLET: 3/4" Female Pipe Thread OUTLET: 3/4" Male Pipe Thread This is the check that screws into the air compressor tank. When this check valve goes bad the air keeps coming out the relief valve on the pressure switch. This check valve is suppose to hold the pressure in the tank and allow the pressure between the outlet of the compressor and the inlet of the tank to release when the pressure switch satisfies. This happens so the compressor does not start with a load or a head pressure on the discharge side. This valve should allow flow one way, thus the term "CHECK-VALVE" is used. If your air compressor runs fine but the minute it shuts off the air keeps coming out the pressure switch them you have a bad check valve. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application
