Airpax Military Surplus Circuit Breaker 3 Pole 15 Amp 240 V Apl-111-5490-1 New

US $110.00

Westerville, Ohio, United States
Mar 3rd

Open on mobile:
QR code

FOR SALE IS A BRAND NEW AIRPAX CIRCUIT BREAKER. THE PART NUMBER IS APL-111-5490-1. THE NSN IS 5925011209107. THE SPECIFICATIONS ARE AS FOLLOWS: AAJE Thread Pitch Diameters +0.1177/+0.1214 inches AAQL Body Style Multipole-multiple actuator type ADAQ Body Length 2.480 inches minimum and 2.500 inches maximum ADAT Body Width 2.250 inches maximum ADTV Case Material Plastic AEBP Center TO Center Distance Between Terminals Parallel TO Length 1.940 inches nominal AEBQ Center TO Center Distance Between Terminals Parallel TO Width 0.750 inches nominal AEBY Distance Between Centerlines OF Mounting Facilities Parallel TO Body Length 2.050 inches minimum and 2.070 inches maximum AEHA Distance Between Centerlines OF Mounting Facilities Parallel TO Body Width 0.750 inches nominal AFJN Fragility Factor Moderately rugged AJEC Boss Height 0.150 inches nominal AJWX Mounting Surface TO Terminal END Distance 2.475 inches nominal AKPX Pole Quantity 3 APNQ ARC Quenching Method Magnetic blowout AXHR Mounting Facility Type AND Quantity 6 threaded hole BBRG Storage Type Unimproved open CBBL Features Provided High inrush protection CMLP Thread Quantity PER Inch 32 CPLM Maximum Continuous Load Current Rating PER Pole 15.0 amperes ac all locations CPRF Operating Voltage Type AND Rating PER Pole IN Volts 240.0 ac all locations CPRG Maximum Interrupting Capacity Current Type AND Rating PER Pole IN Amps 1000.0 ac all locations CPRH Circuit Protection Type Overcurrent all locations CPRJ Trip Release Method Magnetic all locations CPRL Trip Release Characteristic Time delay all locations CPRN Ultimate Trip Rating OF Continuous Current Rating PER Pole IN Percent 150.0 all locations CPRQ Reset Method Manual CPRR Main Contact Tripping Mechanism Type Trip free CPRT Manual Actuator Type AND Quantity 3 toggle CPRW Actuator Function Trip-reset CPRX Actuator Position Designation At each pole CPRY External Actuator Linkage Arrangement One, two, and three linked CPSM Internal Trip Release Configuration Series trip all locations CQJX Nominal Thread Size 0.138 inches CQWN Trip Delay Time IN Seconds PER Rated Continuous Current 2.000 minimum at 200 pct all locations and 10.000 maximum at 200 pct all locations CQXF Inclosure Protection Type FOR Which Designed Fungus resistant FREQ Frequency IN Hertz 400.0 all locations THSD Thread Series Designator UNC TTQY Terminal Type AND Quantity 6 threaded stud IF YOU HAVE ANY QUESTIONS, PLEASE FEEL FREE TO CALL ME 1-614-580-0951. You will not be disappointed. My feedback speaks for itself. If you have any questions please email me and check out the other items I have for sale. If you have problems with your order, PLEASE CONTACT ME BEFORE LEAVING FEEDBACK. Thanks, Mark ATTENTION! – ATTENTION! – NOTICE! – NOTICE! BEFORE LEAVING FEEDBACK PLEASE CONTACT ME. I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE. IF YOU BOUGHT THE WRONG THING, IT IS BROKEN, IF SHIPPING TOOK TOO LONG OR EVEN IF YOU’RE HAVING A BAD DAY. I WANT TO HELP!! I WANT TO KEEP MY FEEDBACK CLEAN.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	AIRPAX
Amperage Rating	15
Model	CIRCUIT BREAKER
Voltage Rating	250
MPN	APL-111-5490-1
NSN	5925011209107
Poles	3
