All New Rigol Ds1052e Digital Oscilloscope 50mhz 1g

US $289.98

China, China
Jan 29th

Open on mobile:
QR code

All New RIGOL DS1052E Digital Oscilloscope 50MHz 1G We can send it to the worldwide, if your country is in the excluded area, please contact us to get quotation! General Introduction for DS1000E Series Digital Oscilloscope DS1000E series are the high-performance, economic digital oscilloscopes. They are widely used in the areas of education, training, production line, research and development. Features and Benefits 2 analog channels, 100MHz bandwidth, 1GSa/s maximum real-time sample rate and 25GSa/s equivalent time sample rate 5.6” TFT QVGA (320X240) with 64K color LCD backlighted display Trigger modes: edge, pulse width, slope, video, alternate trigger Multiple interface configurations: Standard USB Host and USB device, RS-232 and support U disk storage and PictBridge print standards, optional USB-GPIB adapter Advanced Funtions 1 Mpts memory depth Alternate trigger File management Built-in help system Low noiseHigh Performance Keyboard Lock Pass/fail test Waveform record Adjustable trigger sensitivityUser-friendly Design Detailed Introductions for DS1052E Digital Oscilloscope Characteristic: * Real-time sampling rate 1GSa/s, the memory depth reaches as high as 1Mpts * Rich triggering function: The border, the video frequency, the pulse width, the slope, take turn * 6 inch 64k color TFT LCD, clear display profile * The compact design, saves the laboratory bench tabletop space * Integrates USB Host & Device, supports U to take inventory Chu and the Pict Bridge printer * Profile brightness: May adjust the profile brightness, observes the profile effectively * Document supervisor: May operate the U plate conveniently and local saves the document * Embedded help: Long presses the current key 3 seconds to be possible to present this pressed key's help information Triggering function: * Adjustable trigger sensitivity: The effective filtration has the possibility to superimpose on the trigger pip the noise, prevents to trigger by mistake * Alternately triggering: Simultaneously triggers two group different frequency the signals * Slope triggering: Judges triggering based on the signal rise/fall time * Rises & Drop along triggering: Mainly applies in the observation eye chart and so on special signal, generally only then may see in the upscale oscilloscope Performance parameter: Band width: 50MHz Channel number: Double channel + external trigger Real-time sampling rate: 1 GSa/s (single channel), 500 MSa/s (double channel) Equivalent sampling rate: 10GSa/s Rising time: 7 ns Memory depth / Channel pattern: Single channel: Sampling rate 1 GSa/s, Ordinary memory: 16 kpts, Long memory: N.A. Single channel: Sampling rate 500 Msa/s or is lower, ordinary memory: 16 kpts, long memory: 1 Mpts Double channel: Sampling rate 500 Msa/s or is lower, ordinary memory: 8 kpts, long memory: 512 kpts Time base scope: 5 ns/div~50 s/div Burst mode: The border, the video frequency, the pulse width, the slope, take turn Vertical resolution: 8 bits Vertical sensitivity 2 mV/div ~ 10 V/div Biggest input: All Input 1M?||15 pF 300 Vrms Max CATI Trundle range : 500 ms/div ~ 50 s/div Cursor survey: Manual, tracing, automatic sizing Mathematics operation +, -, *, FFT Internal memory: 10 groups of profiles, 10 groups establish U takes inventory Chu: The bitmap saves, CSV saves, the profile saves, establishment memory Connection: USB Device, USB Host, RS-232, P/F Out Demonstrated: 5.6 inch 64k color TFT liquid-crystal display Power source: 100 ~ 240 VACRMS,45 ~ 440Hz, CAT II,50 VA maximum value Chassis Size: 303mm*154mm*133mm (L x W x H) Weight: 2.4Kg Accessories Content: x1 RIGOL DS1052E Digital Oscilloscopes x1 Power Cord x2 Probles PAYMENT We accept online payment here or other payment terms. If there is any import duties or taxes,it is the buyer's responsibility. Please make payment within 3 days after you place your order. Please DO NOT place your order if you are NOT intend to buy. SHIPPING & DELIVERY We will ship out the unit to you by EMS or FedEx or DHL. It will decided by seller according to your location.(EMS Service Only for Russian Customers) We will ship out the unit to the Express company first, it will take about 2-3 days, and then express company will deal with the package, so you can check the tracking number online after about 4 days. Please note this. CONTACT US Welcome!! Please read ALL POLICIES of us before your purchase. If you have additional questions or concerns about this item, please contact us via email or trademanager. We will response the most E-mail within 24 hours. RETURN POLICY If the item is defective, please notify us within 7 days after the receipt of the item. The item shall be return in its original condition, in order to get it refunded or replaced.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DS1052E
Type	Digital
Country of Manufacture	China
