Alpha 3210-y03 1 Conductor 24 Awg. Tc Wire Pvc Wrapped 750ft.

US $99.99

Toledo, Ohio, United States
Jun 9th

Open on mobile:
QR code

alpha 3210-Y03 1 Conductor 24 awg. TC Wire PVC Wrapped 750ft. ALPHA WIRE COMPANY CUSTOMER PRODUCT SPECIFICATION Part Number: 3210 Issue: 4 Page 1 of 1 Pages Issue Date: 5/19/2005 Effective Date: 8/1/2005 Although Alpha Wire Company ("Alpha") makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not ensure product availability. Alpha provides the information and specifications herein on an "AS IS" basis, with no representations or warranties, whether express, statutory or implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever, even if Alpha has been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein. 711 Lidgerwood Ave Elizabeth, NJ 07207-0711 Toll Free 1-800-52 ALPHA • T: 1-908-925-8000 • F: 908-925-5411 • Email: info@alphawire.com www.alphawire.com A. Construction Diameters (In) 1) Component 1 1 X 1 COND a) Conductor 24 (19/36) AWG TC b) Insulation 0.010" Wall, Nom. PVC/ 0.003" Wall NYLON 0.051 (1) Color Code Alpha Wire Company Color Code G Cond Color Cond Color Cond Color 1 WHITE 2) Shield TC BRAID Shield,90% Coverage, Min. 3) Jacket 0.010" Wall, Nom.,PVC 0.093 (0.100 Max.) a) Color(s) SLATE b) Print ALPHA WIRE-* P/N 3210 ROHS * = Factory Code B. Industry Approvals 1) Military a) Component 1 MIL-W-16878/Type B/N 105°C / 600 V RMS 2) EU Directive 2002/95/EC(RoHS): All materials used in the manufacture of this part are in compliance with EU Directive 2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture. 3) California Proposition 65: The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. C. Physical & Mechanical Properties 1) Temperature Range -55 to 105°C 2) Bend Radius 10X Cable Diameter 3) Pull Tension 5.7 Lbs, Maximum D. Electrical Properties (For Engineering purposes only) 1) Voltage Rating 600 V RMS 2) Ground Capacitance 99 pf/ft @1 kHz, Nominal 3) Inductance 0.06 ?H/ft, Nominal 4) Conductor DCR 23.9 ?/1000ft @20°C, Nominal 5) OA Shield DCR 10.6 ?/1000ft @20°C, Nomina Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Alpha
MPN	3210
