Altronix Acm8cbe Power Controller

US $40.00

North Canton, Ohio, United States
Jun 9th

Open on mobile:
QR code

Standard Office Hours: Monday through Friday- 9:00AM-5:00PM Eastern Standard Daylight Time 330-413-1195 Our staff at eComponents have a multitude of technical capabilities, ranging from computer and server testing & repair to point of sale system assembly and equipment refurbishment. We are all a distributor of electronic equipment and components. If your business is in need of a hardware solution please feel free to contact us. eComponents would like to sell the following: ACM8CBE 8 PTC Outputs Access Power Controller. 12-24V AC or DC. Encl. ACM8CBE converts one (1) 12 to 24 volt AC or DC input into eight (8) independently controlled PTC protected outputs. Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. The unit will route power to a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes. Unit is designed to be powered by one common power source which will provide power for both the board operation and locking devices, or two (2) totally independent power sources, one (1) providing power for board operation and the other for lock / accessory power. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the eight (8) outputs Input: 12 to 24 volt AC or DC operation (setting not required), (0.6 amp @ 12volt, 0.3 amp @ 24 volt current consumption with all relays energized). Power supply input options: a) One (1) common power input (board and lock power). b) Two (2) isolated power inputs (one (1) for board power and one (1) for lock/accessory power). Eight (8) Access Control System trigger inputs: a) Eight (8) normally open (NO) inputs. b) Eight (8) open collector sink inputs. c) Any combination of the above. Output: Eight (8) independently controlled outputs: a) Eight (8) Fail-Safe and/or Fail-Secure power outputs. b) Eight (8) dry form "C" 5 amp rated relay outputs c) Any combination of the above Eight (8) auxiliary power outputs (unswitched). Output ratings: - PTCs are rated 2.5 amp each. Main fuse is rated at 10 amp. Note: Total output current is determined by the power supply, not to exceed a maximum of 10 amp total. Features: Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs. Fire Alarm disconnect input options: a) Normally open (NO) or normally closed (NC) dry contact input. b) Polarity reversal input from FACP signaling circuit. FACP output relay (form "C" contact rated @ 1 amp 28VDC not evaluated by UL). Removable terminal blocks facilitate ease of installation. Visual Indicators: Red LEDs indicate outputs are triggered (relays energized). Green LED indicates FACP disconnect is triggered. Electrical: Operating temperature: 0° C to 49° C ambient. BTU/Hr.: - 12VDC or 12VAC: 3.68 BTU/Hr. - 24VDC or 24VAC: 3.68 BTU/Hr. We ship internationally to all countries given that the item qualifies for the eBay international shipping program. Please contact us if you'd like an estimated shipping cost, which we can provide prior to completing the transaction. Also, because we try to be as accommodating as possible, we are happy to use your business/personal UPS account number. If you'd like us to use our UPS account it would be greatly appreciated if you'd inform us of whether or not the product is being shipped to a residential, or a commercial location. eComponents guarantees that your item will be shipped in no less than 2 business days of receipt of payment. In cases where the item we're shipping is fragile, sensitive, or larger than normal we will use our insta-pak foam packing material to assure the safest transportation of your purchase. Under all other circumstances, in which the product does not demand insta-pak foam, our experienced (20 years) shipping department will package the item neatly and professionally with pink or clear bubble. Local pick-up is available for your convenience. Please contact us at the number above prior to your arrival at our warehouse. Thank you. Product Discrepancies If you receive an item that is DOA, please contact us immediately and we will work to resolve the issue, whether it be through a partial refund, a full refund, or a product replacement. For items that are inaccurately described, or damaged upon arrival we ask that you contact us immediately with descriptions (photos are preferred) that are inaccurate. Description should include part number discrepancies, photos of the damage, and any other relevant information that will assist all parties involved in resolving the issue. Photographs Many of our listings include photographs that are simply a model, or representation of the actual product you will receive. In cases where we have quantities greater than 1 the photos will not be updated. If you'd feel more comfortable seeing the actual product you'll be purchasing, please contact us and we will provide you with photographs. Returned Merchandise Authorization (RMA) Under any circumstances in which you'd like to return your item, the following requirements must be met: Notify eComponents within 14 days of final transaction, otherwise the return will not be accepted. Buyer pays return shipping. Shipping cost will be incurred by the us in all cases where we replace a product. For any questions regarding this product, or for any questions regarding additional needs, concerns, etc., please contact us at the number above, or through our eBay email and we will do our best to provide you with a solution./td>

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Altronix
Type	Power Controller
Model	ACM8CBE
Country/Region of Manufacture	United States
MPN	ACM8CBE
UPC	782239933273
