Altronix Al400ulacm Power Supply 8 Fuse 12dc/3.5a Or 24dc/3a

US $259.00

Homosassa, Florida, United States
Jun 9th

Open on mobile:
QR code

Input: Input 115VAC 60Hz rated @ 3.5 amp. Power supply input options: a) One (1) common power input for ACM8/ACM8CB and lock power (factory installed). b) Two (2) isolated power inputs - One (1) to power the ACM8/ACM8CB and one (1) for lock accessory power, (external power supply is required). (Current is determined by the power supply connected, not to exceed a maximum of 10 amp total). Eight (8) Access Control System trigger inputs. Input options: a) Eight (8) normally open (NO) inputs. b) Eight (8) open collector inputs. c) Any combination of the above. Output: 12VDC or 24VDC outputs. 12VDC @ 4 amp supply current or 24VDC @ 3 amp supply current. Class 2 Rated power limited outputs. Eight (8) independently controlled outputs. Output options: a) Eight (8) Fail-Safe and/or Fail-Secure power outputs. b) Eight (8) form "C" 5 amp rated relay outputs c) Any combination of the above. Eight (8) auxiliary power outputs (unswitched) Output ratings: - Fuses are rated @ 3.5 amp. Filtered and electronically regulated outputs (built-in power supply). Supervision: AC fail supervision (form "C" contacts). - Notification trigger is selectable for 30 seconds (factory set) or 6 hours. Low battery and battery presence supervision (form "C" contact). Features: Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs. Fire Alarm disconnect input options: a) Normally open (NO) or normally closed (NC) dry contact input. b) Polarity reversal input from FACP signaling circuit. Alarm output relay indicates that FACP input is triggered (form "C" contact rated @ 1 amp 28VDC not evaluated by UL). Short circuit and thermal overload protection. Visual Indicators: Red LEDs indicate outputs are triggered (relays energized). Green LED indicates FACP disconnect is triggered. AC input and DC output LED indicators. Battery Backup: Built-in charger for sealed lead acid or gel type batteries. AL400ULXB (Power Supply Board) maximum charge current 0.7 amp. Automatic switch over to stand-by battery when AC fails. Zero voltage drop when unit switches over to battery backup (AC failure condition). Battery fail and battery presence supervision (form "C" contact). Electrical: Operating temperature: 0° C to 49° C ambient. ACM8 board main fuse is rated at 10 amp. BTU/Hr.: - 12VDC: 24.57BTU/Hr. - 24VDC: 36.85BTU/Hr. Lifetime WarrantyUL listed for Access Control System Units (UL294) download UL file CUL Listed - CSA Standard C22.2 No.205-M1983, Signal Equipment download cUL file CSFM - California State Fire Marshal Approved download CSFM file MEA - NYC Department of Buildings Approved Enclosure: Wall mount enclosure for indoor use. Accommodates up to two (2) 12VDC/12AH batteries. Dimensions 15.5"H x 12.25"W x 4.5"D (394mm H x 311mm W x 114mm D) 1.125" and 1.375" combination knockouts. Weights (approximate): Product Weight: 10.7 Lbs (4.85 kg) Shipping Weight: 12 Lbs (5.44 kg)

“New out of box all items included”

Brand	ALTRONIX
Input Frequency (Hz)	60
MPN	AL400ULACM
Input Voltage	115VAC
SKU	G0802094
Output Current (Amps)	12VDC @ 4A or 24VDC @ 3A
Finish	Grey
Standards	UL294, CSFM , MEA , CUL
Includes	Battery leads, Cam Lock
Number of Outputs	12VDC or 24VDC
Item	Power Supply 8Fuse 12Dc/3.5A Or 24Dc/3A
Enclosure Depth (In.)	4.50
Material	Steel
Enclosure Height (In.)	15.5
Type	Access Power Controller
Enclosure Width (In.)	12.00
Voltage Output	12VDC or 24VDC
Sub-Category	Power Supply/Charger
Batteries Required	No
Package Quantity	1
