Altronix Al600ulm 12vdc Or 24vdc @ 6 Amp, Monitoring - Large Cabinet With Key

US $120.00

Irvine, California, United States
Jul 9th

Open on mobile:
QR code

Altronix AL600ULM 12VDC or 24VDC @ 6 amp, AC and battery monitoring Large cabinet --- key included Input Input 115VAC, 60Hz, 3.5A. Input fuse rated @ 3.5A/250V. Fire Alarm Panel or Access Control System trigger inputs. N.O. or N.C.supervised trigger input and polarity reversal trigger input. Output 12VDC or 24VDC selectable outputs. 6A supply current. Five (5) PTC protected Class 2 Rated power limited outputs, rated @ 2A (auto-resettable). Output relay energizes when unit is triggered (form "C" contact rated 1A @ 28VDC). Filtered and electronically regulated output. Short circuit and thermal overload protection. Battery Backup Built-in charger for sealed lead acid or gel type batteries. Automatic switch over to stand-by battery when AC fails. Supervision AC fail supervision (form "C" contacts). Notification trigger is selectable for 30 seconds (factory set) or 6 hours. Low battery supervision (form "C" contacts). Battery presence supervision (form "C" contacts). Power fail supervision relay (form "C" contacts). Visual Indicators AC input and DC output LED indicators (power supply board). Red LEDs indicate condition of power outputs (multi-output board). Power & input trigger LEDs (multi-output board). Temperature Operating: 0° C to 49° C (32° F to 120° F). Storage: - 20° C to 70° C ( - 4° F to 158° F). Relative Humidity 85% +/- 5%. BTU/Hr (approx.): 12VDC: 37 BTU/Hr. 24VDC: 74 BTU/Hr. Dimensions: 15.75" x 12" x 4.5"

“Key included. Tested and works as expected. Batteries not included. A/C cord included.”

Brand

Altronix

Model

Altronix AL600ULM

MPN

AL600ULB

Type

Cameras
