Altronix Power Supply 16 Fuse 24vac @ 10a Rack Model: Vertiline16c

US $360.00

Batavia, Ohio, United States
Feb 12th

Open on mobile:
QR code

Model: VERTILINE16C SKU: 670112 Vertiline16C CCTV Rack Mount Power Supply provides 16 fuse protected power outputs in a space saving 1U EIA 19" rack mount chassis which may be rack, wall or shelf mounted. This unit features individually selectable 24VAC and/or 28VAC power outputs with surge suppression. Vertiline CCTV Rack Mount Power Supplies are also available in eight (8) and twenty-four (24) output models with various power ratings. Vertiline16C Sixteen (16) Fuse Protected AC CCTV Rack Mount Power Supply. 24VAC or 28VAC @ 10 amp · Input: · 115VAC 60 Hz., 3 amp. · Output: · Sixteen (16) individually selectable 24VAC or 28VAC power outputs with OFF position. · 24VAC or 28VAC @ 10 amp max. total (0.625 amp per device, 3 amp max.). · Sixteen (16) external blade fuse protected outputs rated @ 3 amp. · Main fuse rated @ 10 amp. · Surge suppression. · Electrical: · Operating temperature: 0° C to 49° C ambient. · BTU/Hr.: · - 24VAC: 122.84 BTU/Hr. · - 28VAC: 143.31 BTU/Hr. · System AC input VA requirement: 345VA. · Features: · Sixteen (16) power LEDs. · Illuminated master power disconnect circuit breaker with manual reset. · IEC 320 - 3-wire grounded line cord (detachable). · Removable terminal blocks with locking screw flange. · Lifetime Warranty SPECS ITEM Power Supply 16Fuse 24Vac @ 10A Rack TYPE CCTV Ac, Rack Mount MATERIAL Steel FINISH Black ENCLOSURE DEPTH (IN.) 8.50 ENCLOSURE WIDTH (IN.) 19.13 ENCLOSURE HEIGHT (IN.) 3.25 BATTERIES REQUIRED No NUMBER OF OUTPUTS 16 INPUT VOLTAGE 115VAC VOLTAGE OUTPUT 24VAC or 28VAC OUTPUT CURRENT (AMPS) 24VAC or 28VAC @ 10A INPUT FREQUENCY (HZ) 60 STANDARDS UL 2044 Commercial CCTV, CUL, CE INCLUDES Line Cord, Removable Terminal Blocks, Mounting Brackets SUB-CATEGORY Power Supply: Rack Mount UNSPSC 39121004 WEIGHT 14.950000 DESCRIPTION Power Supply 16Fuse 24Vac @ 10A Rack, Type CCTV Ac, Rack Mount, Material Steel, Finish Black, Enclosure Depth 8.50 In, Enclosure Width 19.13 In, Enclosure Height 3.25 In, Input Voltage 115VAC, Voltage OUTPut 24VAC or 28VAC, OUTPut Current 10A Amps, Input Frequency 60 Hz, Standards UL2044 Commercial CCTV, CUL, Includes Line Cord, Removable Terminal Blocks, Mounting Brackets

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Altronix
MPN	782239944811
Model	VERTILINE16C
