Am Radio If/osc Coil Kit: Set Of 4: 1st, 2nd, 3rd If 455khz, Oscillator 796khz

US $360

Westerly, Rhode Island, United States
Jun 9th

Open on mobile:
QR code

AM Radio IF/ OSC Coil Kit - Set Of 4 1st, 2nd, 3rd IF 455Khz and Oscillator 796 Khz Back in Stock! Ideal for replacement in vintage transistor radios or new construction projects Oscillator (Red) Specifications: • Type: sub-miniature PC mounting • Inductance: (1-3) 360?H±8% • Unloaded Q: 80 min. • Stray capacitance: 8.0pF max. • Frequency: 796 kHz • Turns: 1-2: 92, 2-3: 3, 4-6: 9 • Dimensions: .40” Wide x .40” Deep x .50” High (Not including Pins) 1st IF (Yellow), 2nd IF (White), 3rd IF Black Specifications: • Type: sub-miniature PC mounting • Frequency: 455 kHz • Loaded Q: 35 ± 20% • Unloaded Q: 75 ± 20% • Tuning capacity: 180pF ± 10% • Dielectric strength: 100VDC for 1 minute • Dimensions: .40” Wide x .40” Deep x .50” High (Not including Pins) See wiring diagrams in above photos Selling these as a set of 4 pieces for a very good price. I import these from overseas. They sell out very quickly and unfortunately take about 8 weeks to get in when I reorder. Hard to find all four needed types I always combine items when possible to save you on shipping costs. Be sure to request an invoice/total BEFORE PAYING when buying multiple items. Check out our other Ebay items. A Note to International Customers: First I want to say that when we receive an order, it is shipped promptly within 1-3 days. Once the order is brought to the post office and shipped, it is out of our hands. Delivery outside of the United States can take anywhere from 1 week all the way up until 12 weeks (Typical though is one to four weeks). There are numerous reasons for the delay. Typically, packages are delayed in customs, first in the United States and then in overseas customs. We cannot control the time packages are in customs. If you contact us to see where your item is, and we tell you it has been shipped, that is all we can do. On small packages, we do not use delivery confirmation because of the high cost. The cost to use confirmation overseas will far exceed the price of the item purchased. If the package has not arrived by 12 weeks, we will issue you a refund or a replacement if the item is available. According to Ebay statistics, only 19% of sellers in the United States will ship overseas. And according to Ebay surveys, those who do not ship overseas site customer complaints from long delivery times as the reason. We have chosen to do business with our international friends. However, we ask for your patience. Too often we get emails asking where my item is when it has not even been a week or two. Our next choice will be to either discontinue international sales or charge for delivery confirmation which will add considerably to the cost. Please be patient. Note, it is the responsibility of the buyer to pay all and any custom fees. We do not know how much these fees are. You will have to inquiry within your own country. Thank you
