Amd Am2504pc Successive Approximation Register Pdip24 Used Om0195z

US $29.31

Caerphilly, United Kingdom
Jul 11th

Open on mobile:
QR code

AMD AM2504PC SUCCESSIVE APPROXIMATION REGISTER PDIP24 USED OM0195Z AMD AM2504PC SUCCESSIVE APPROXIMATION REGISTER PDIP24 USED OM0195Z 1 Piece These genuine AMD parts are date coded 83, they were retrieved from a Le Croy Model 6810 waveform recorder. The chips were extracted from what was a working unit we have classified them as used, but they are in very good condition and should still function perfectly. Pins may need a little straightening as extracted from sockets, see photographs for general condition. Manufacturer: Advanced Micro Devices, Inc. Description: Serial In Parallel Out, TTL/H/L Series, 12-Bit, Right Direction, True Output, TTL, PDIP24 Mfr Package Description PLASTIC, DIP-24 Status Discontinued Logic IC Type SERIAL IN PARALLEL OUT Sub Category Shift Registers Count Direction RIGHT Family TTL/H/L fmax-Min 15.0 MHz JESD-30 Code R-PDIP-T24 JESD-609 Code e0 Load Capacitance (CL) 15.0 pF 1.5E7 Hz Number of Bits 12 Number of Functions 1 Number of Terminals 24 Operating Temperature-Min 0.0 Cel Operating Temperature-Max 70.0 Cel Output Polarity TRUE Package Body Material PLASTIC/EPOXY Package Code DIP Package Equivalence Code DIP24,.6 Package Shape RECTANGULAR Package Style IN-LINE Peak Reflow Temperature (Cel) NOT SPECIFIED Power Supplies (V) 5 Propagation Delay (tpd) 40.0 ns Qualification Status Not Qualified Seated Height-Max 5.461 mm Supply Voltage-Nom (Vsup) 5 Surface Mount NO Technology TTL Temperature Grade COMMERCIAL Terminal Finish Tin/Lead (Sn/Pb) Terminal Form THROUGH-HOLE Terminal Pitch 2.54 mm Terminal Position DUAL NOT SPECIFIED Trigger Type POSITIVE EDGE Length 31.877 mm Width 15.24 mm Additional Feature SUCCESSIVE APPROXIMATION REGISTER FOR DATASHEET SEARCH… AM2504PC Dispatch time: Will dispatch within 1 working day of receiving cleared payment. Payment We accept the following payment methods: PayPal Please contact us if you have any questions. Service We purchase Surplus Stock. If you or your company have items similar to the above, or indeed any electronic components surplus to requirements, please contact us with details as we are keen to increase our stock profile. AMD AM2504PC SUCCESSIVE APPROXIMATION REGISTER PDIP24 USED OM0195Z AMD AM2504PC SUCCESSIVE APPROXIMATION REGISTER PDIP24 USED OM0195Z These genuine AMD parts are date coded 83, they were retrieved from a Le Croy Model 6810 waveform recorder. The chips were extracted from what was a working unit we have classified them as used, but they are in very good condition and should still function perfectly. Pins may need a little straightening as extracted from sockets, see photographs for general condition. Description: Serial In Parallel Out, TTL/H/L Series, 12-Bit, Right Direction, True Output, TTL, PDIP24 We purchase Surplus Stock. If you or your company have items similar to the above, or indeed any electronic components surplus to requirements, please contact us with details as we are keen t

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	MPN	AM2504PC
Brand	AMD
UPC	Does not apply
