American Carbide Tool Carbide-tipped Tool Bit For Offset End Cutting

US $9.00

San Antonio, Texas, United States
Aug 25th

Open on mobile:
QR code

Size: FR 12 FR-style tool shape has a 0-degree end cutting angle and is offset for turning, facing, boring, and straddle facing close to chuck jaws C2 grade uncoated carbide tip for machining of cast iron and nonferrous materials Right-hand cutting direction for right-to-left feed Positive rake angle provides a sharp edge for making continuous cuts Square steel shank fits square toolholders Product Specifications Ean 0726761556715 Global Trade Identification Number 00726761556715 Industry Standard Identifier FR 12 Length 4.5 inches Measurement System Inch Number of Items 1 Part Number FR 12 C2 Shank Width 0.75 inches Size FR 12 UPC 726761556715 Specification for this product family Brand Name American Carbide Tool Corner Radius 0.03125 inches Hand Orientation Right Hand Item Shape Fr Lead Angle 7 degrees Manufacturer Grade C2 Material Carbide-Tipped Shank Material Steel Shank Type Square Style Offset End Cutting UNSPSC Code 27110000 Product description Size:FR 12 The American Carbide Tool FR-style C2 grade carbide-tipped brazed tool bit has a right-hand cutting direction and a 0-degree end cutting angle for offset turning, facing, boring, or straddle facing on cast iron and nonferrous materials. The FR-style tool shape is offset, which allows its end cutting edge to be used close to chuck jaws on a lathe or for boring mill applications. The tool has a positive, 7-degree rake angle that provides a sharp edge for making continuous cuts, and a right-hand cutting direction for right-to-left feed. The tool has a C2 grade uncoated carbide tip, which provides good resistance to shock and wear for machining on cast iron and nonferrous materials. Carbide is harder than high-speed or cobalt steel, making it more wear resistant at high speeds and providing longer tool life. The tip is brazed to a square steel shank that fits square toolholders. Brazed tools, often called single-point brazed carbide-tipped tools, are used for metal shaping on lathes or screw machines. These single-point tools have a cutting edge at one end that is a carbide tip brazed to a steel shaft. They come in multiple geometry styles for cutting different shapes and are identified by a lettering standard that conforms to American National Standards Institute (ANSI) B212.1 specifications. The tool has a side cutting edge and end cutting edge, with the tool shape style defining which cutting edge is principal and auxiliary. Brazed tools are available in three hand options: right, left, and neutral. A right-hand tool has its principal cutting edge on the right side of the tool to feed into the workpiece from right to left, a left-hand tool feeds into the workpiece from left to right, and a neutral-hand tool will cut either left to right or right to left. The side cutting and end cutting edge angles, in combination with the angle at which the tool is positioned in relation to the workpiece (also called the lead angle), influence the tool's cutting shape and action. Rake angles are the degree of inclination of the face toward or away from the cutting edge. They may be positive for sharp, continuous cuts, negative for heavy, interrupted cuts, or neutral for a true 90-degree cut. The tip, or nose, of the tool performs the finish cut on the workpiece. In general, a larger tip radius will produce a better surface finish and permit a faster feed rate than a smaller tip radius. American Carbide Tool manufactures standard single-point brazed carbide-tipped tools, and precision ground cutting tools and inserts. The company, founded in 1953, is headquartered in Canton, OH.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Tool Bit Material	Carbide
Brand	American Carbide Tool
MPN	Does Not Apply
UPC	Does Not Apply
