American Dynamics 2083-02c Auxiliary Follower

US $535.00

Houston, Texas, United States
Mar 3rd

Open on mobile:
QR code

SPECIFICATIONS Model Numbers AD2083-02C . . . . . . . . . . . . . . . . .120 VAC, 50/60 Hz AD2083-02C-1 . . . . . . . . . . . . . . . .230 VAC, 50/60 Hz Operational Dome Outputs . . . . . . . . . . . . . . .16 RS-422 total, four groups of four connectors Address Range . . . . . . . . . . . . . . . .11 blocks of 99 for maximum 1024 Targets (Presets) . . . . . . . . . . . . . .Stores up to 16 presets per suitablyequipped SpeedDome Ultra or SpeedDome Optima Series domes Dome Alarms . . . . . . . . . . . . . . . . .Up to four (on suitably-equipped domes transmitted over dome data cabling) Alarm Output . . . . . . . . . . . . . . . .RS-232 RJ-45 direct connection to system CPU Alarm Indication . . . . . . . . . . . . . .LED and Form-C relay outputs LEDs . . . . . . . . . . . . . . . . . . . . . . . . .Power, alarm and code Matrix Switcher . . . . . . . . . . . . . . .American Dynamics High Speed Data Line and/or Manchester code connection Connectors High Speed Data Line . . . . . . . . .BNC, in/out Manchester Code . . . . . . . . . . . . .One 12-pin removable screw terminal RS-232 . . . . . . . . . . . . . . . . . . . . . . .RJ-45 in/out, cascadable RS-422 . . . . . . . . . . . . . . . . . . . . . . .Eight 12-pin removable screw terminals Electrical Supply Voltage AD2083-02C . . . . . . . . . . . . . . .120 VAC, 50/60 Hz AD2083-02C-1 . . . . . . . . . . . . .230 VAC, 50/60 Hz Power Consumption . . . . . . . . . .8.0 watts (nominal) Mechanical Dimensions (H x W x D) . . . . . . .89 x 483 x 203 mm (3.5 x 19.0 x 8.0 in) Unit Weight . . . . . . . . . . . . . . . . . .3.2 kg (7 lbs) Shipping Weight . . . . . . . . . . . . . .4.1 kg (9.1 lbs) Color . . . . . . . . . . . . . . . . . . . . . . . .Black Mounting . . . . . . . . . . . . . . . . . . . .Universal wall, surface and rack (19-inch EIA) Environmental Operating Temperature . . . . . . . .0° to 40° C (32° to 104° F) Storage Temperature . . . . . . . . . .-40° to 70° C (-40° to 155° F) Humidity . . . . . . . . . . . . . . . . . . . . .98% RH (noncondensing) Regulatory Emissions . . . . . . . . . . . . . . . . . . . .FCC Part 15, Subpart B Class A CE: EN55022 Class B Immunity . . . . . . . . . . . . . . . . . . . .CE: EN50082-1 Safety . . . . . . . . . . . . . . . . . . . . . . . .UL2044 cUL: CSA C22.2 No. 1-94 CE: EN60950 Dome Compatibility SpeedDome Ultra Series SpeedDome Optima Series The AD2083-02C Series provides economical distribution of American Dynamics RS-422 code to the SpeedDome® Ultra and SpeedDome Optima Series domes. Using the AD2083-02C Distributor, multiple dome sites can be driven from the powerful family of American Dynamics Matrix Switcher/Controller Systems. The AD2083-02C outputs commands for pan, tilt, focus, iris, zoom, preset and pattern control. It can also receive alarm information from SpeedDome Ultra Series domes and relay it to an American Dynamics Matrix System. In addition, an alarm from any of the domes activates a Form C relay. Quick-connect screw terminals and diagnostic LEDs facilitate efficient installation and service. The universal mount enables mounting to the front or rear of equipment racks, or flat on a wall or horizontal surface. Supports presets stored in the dome and simplex RS-422 for the Speed Dome Optima LT or situations where the data return line is not available such as fiber optics or microwave links.

“like new condition”

Brand	American Dynamics
Model	2083-02C
