Amp 1-103327 15 Pin Breakway Header

US $2.00

Caledonia, New York, United States
Jun 9th

Open on mobile:
QR code

AMP MODU Breakaway Headers 15P HEADER TIN single row. Stock 12-8-7 Product Type Features Applies To Printed Circuit Board Connector Style Plug PCB Mounting Orientation Vertical Connector Type Header Row-to-Row Spacing 2.54 mm [ .1 in ] Stabilizers Without Strain Relief Without Board Standoff Without Product Type Connector Gasket Without Configuration Features Number of Positions 10 Number of Rows 1 Keyed No Selectively Loaded No Electrical Characteristics Dielectric Withstanding Voltage 750 V Body Features Header Type Breakaway Post Size .64 mm [ .025 in ] Contact Features Contact Protection Without Contact Shape Square Contact Type Pin Contact Base Material Phosphor Bronze Contact Mating Area Plating Thickness (µin) 100 – 200 Solder Tail Contact Plating Material Tin-Lead over Nickel Contact Mating Area Plating Material Tin-Lead Contact Current Rating (A) 3 Termination Features Termination Post Length 3.05 mm [ .12 in ] Termination End Plating Thickness (µin) 100 – 200 Termination End Plating Material Matte Tin-Lead Over Nickel Termination Method to PC Board Through Hole Mechanical Attachment PCB Mounting Style Through Hole PCB Mount Retention Without Panel Mount Retention Without Mating Connector Lock Without Housing Features Centerline 2.54 mm [ .1 in ] Housing Color Black Housing Material Thermoplastic Dimensions Mating Post Length 5.84 mm [ .23 in ] Usage Conditions Operating Temperature Range (°C) -65 – 105 High Temperature Housing No Operation/Application High Speed Serial Data Connector No Industry Standards UL Flammability Rating UL 94V-0 Approved Standards CSA LR7189, UL E28476 Packaging Features Packaging Quantity 200 Packaging Method Carton Other Comment Headers may be broken to desired number of positions using Hand Tool No. 91406-1, or Tool Kit No. 314818-1. Other tail lengths are available, consult TE Connectivity. On Feb-26-15 at 07:50:15 PST, seller added the following information: Thank you for shopping with railside Visit our store for 1000's of items! inkFrog Analytics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	AMP
Manufacturer	AMP
MPN	1-103327
